Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

LED Strip ProPlus CC High CRI 120LEDs/m 14.4W/m 24V IP65 CRI>95

SKU:

Z-CC2835-1202465GLE-CW-5

Length

500 Centimeter

LED Colour

Cool White 6000K Natural White 4000K Warm White 3000K

Product variants

Please for Pricing

Notify me when it's back in stock

Description

Plus Series using top quality material, such as Epistar chip, Intermatix phosphor powder; IC constant current series assure same LED working current under fluctuant input voltage, and generate same LED brightness even running in long length; Decorating backlight and indirect lighting for showcase, shelf, cabinet,billboard, signage. hotel, garden, bridge, corridor, celling, stair, theatre etc. IP65 rated.

Specifications

Brand

Archilight
Series

ProPlus Ultra High CRI Series
Power Rating

14.4 Watt
Operation Mode

Constant Voltage
Operating Temperature

-10°C~50°C
Warranty

5 Year
Width

1 cm
Height

0.2 cm
Weight

0.2 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What applications is this LED strip designed for?

This archilight ProPlus LED strip is intended for decorative backlighting and indirect lighting. It is suitable for showcase, shelf, cabinet, billboard, signage, hotel, garden, bridge, corridor, ceiling, stair, and theatre lighting applications.

What color temperature options are available in this product family?

This parent product family includes 3000K warm white, 4000K neutral white, and 6000K cool white variants. These are the only color temperature differences shown across the child variants.

Is this LED strip suitable for outdoor or damp-area use?

Yes, this LED strip is IP65 rated. That makes it suitable for applications where an IP65-rated linear LED strip is required, including listed outdoor categories such as garden, bridge, and outdoor linear lighting.

Does this LED strip include a driver?

No, the driver is not included with this product family. The parent model and all listed child variants are marked as driver_not_included.

Is this LED strip dimmable?

Dimming is optional for this product family. The parent model and listed variants are marked as dimmable_optional, so dimming support depends on the selected compatible control setup.

What are the main electrical and physical specifications?

This LED strip is rated at 14.4W per meter and uses 24V power input. The strip is listed as 10 mm wide and 2 mm high, with a product weight of 0.2 kg.

What does CRI greater than 95 mean for this LED strip?

The parent product name specifies CRI greater than 95, indicating a high color rendering LED strip. This makes it a strong fit for applications where color appearance is important, such as showcases, cabinets, signage, and display lighting.

What warranty is provided for this LED strip family?

This product family is listed with a 5-year warranty period. The same 5-year warranty value is shown on the parent model and all listed child variants.

Model	Power	LED Density	Cuttable	IP Rating
LED Strip Pro High-efficiency 140LEDs/m 15W/m 24V IP65 CRI>90	15W	140LEDs/m	50mm	IP65	View
LED Strip Pro High-efficiency 70LEDs/m 10.8W/m 24V IP65 CRI>90	10.8W	70LEDs/m	100mm	IP65	View
LED Strip Pro High-Density 280LEDs/m 14W/m 24V IP65 CRI>90	14W	280LEDs/m	25mm	IP65	View
LED Strip Pro High-Density 280LEDs/m 14W/m 24V IP20 CRI>90	14W	280LEDs/m	25mm	Indoor	View
LED Strip ProPlus CC High CRI 120LEDs/m 14.4W/m 24V IP20 CRI>95	14.4W	120LEDs/m	50mm	Indoor	View
