Description
Description
Features
100~305VAC wide input range |
Built-in active PFC |
Protections: Short circuit / Over voltage/Over temperature |
No load power consumption <0.5W |
High efficiency up to 92% |
Suitable for LED lighting and street lighting applications |
Cooling by free air convection |
100% full load burn-in test |
5 years warranty |
General Specification
AC input voltage range | 100~305VAC;142~431VDC |
AC inrush current | Cold start, 40 at 230VAC |
DC adjustment range | ±10% rated output voltage |
Over voltage protection | 110%~140% rated output voltage |
Setup, rise, hold up time | 500ms |
Withstand voltage | I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 1.5kVAC |
Working temperature | -40~+80°C (refer to output derating curve) |
Safety standards | UL8750 approved |
EMC standards | EN55015, EN61000-3-2 class C,EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, GB17743,GB17625.1 |
Dimension (LxWxH) | 199x63x35.5 |
Packing | 16pcs / 14.2kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesELG Series
-
Power Rating100 Watt
-
Output Voltage286 Volt
-
Rated Current0.35 Ampere
-
Input Voltage-40V~80V
-
Standards MetBSMI,CB,CE,EAC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty5 Year
-
Length19.9 cm
-
Width6.3 cm
-
Height3.55 cm
-
Weight0.85 kg
