Name: Mean Well ELG-240-24B Power Supply 240W 24V - Dimmable 10A
Brand: Mean Well
SKU: ELG-240-24B
Price: 159.39 NZD
Availability: InStock

☎ 0800 88 87 86 | +64 22 522 4414

Apply Wholesale and Trade Account Contact us

ELG-240-24B is the 24V output model of this series: rated current 10A, typical efficiency 92%.

ELG-240 series is a 240W AC/DC LED driver featuring the dual mode constant voltage and constant current output. ELG-240 operates from 100～305VAC and offers models with different rated voltage ranging between 24V and 54V. Thanks to the high efficiency up to 93%, with the fanless design, the entire series is able to operate for -40 ℃ ~ +90 ℃ case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. ELG-240 is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system

Features

Constant Voltage + Constant Current mode output
Metal housing design with functional Ground
Built-in active PFC function
No load / Standby power consumption <0.5W
IP67 / IP65 rating for indoor or outdoor installations
Type HL for use in Class I, Division 2 hazardous (Classified) location.
Function options: output adjustable via potentiometer; 3 in 1 dimming (dim-to-off); Smart timer dimming; DAL I
Typical lifetime>50000 hours
5 years warranty

Typical applications

LED street lighting
LED architectural lighting
LED bay lighting
LED floodlighting

Brand

Mean Well
Series

ELG Series
Power Rating

240 Watt
Output Voltage

24 Volt
Rated Current

10 Ampere
Input Voltage

100V~305V
Standards Met

BSI,CB,CCC,CE,EAC,ENEC,KC,RCM,UL,GlobalMark,BIS,EMC,UKCA
Operation Mode

Constant Current,Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

5 Year
Length

24.4 cm
Width

7.1 cm
Height

3.75 cm
Weight

1.22 kg

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well S-ELG-240-24-3Y Power Supply 240W 24V 10A — 3-Wire Input (with Earth)	240W	24V	10A	IP67	View
Mean Well ELG-240-24 Power Supply 240W 24V 10A	240W	24V	10A	IP67	View
Mean Well ELG-240-48 Power Supply 240W 48V 5A	240W	48V	5A	IP67	View
Mean Well ELG-240-24-3Y Power Supply 240W 24V 10A — 3-Wire Input (with Earth)	240W	24V	10A	IP67	View
Mean Well ELG-240-48A-3Y Power Supply 240W 48V - Adjustable 5A — 3-Wire Input (with Earth)	240W	48V	5A	IP65	View
Mean Well ELG-240-48DA-3Y Power Supply 240W 48V - DALI 5A — 3-Wire Input (with Earth)	240W	48V	5A	IP67	View
