Mean Well GE12I05-P1J Power Supply 10W 5V
Please Login for Pricing
Description
Description
The GE12I05 is a 12W Mean Well power converter.
Key Features
- ✓ Protections: Overload / Over voltage
- ✓ Safety approvals: UL60950-1, CSA C22.2, TUV EN60950 -1, AS/NZS 60950.1, CCC GB4943
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesGE Series
-
Power Rating10 Watt
-
Output Voltage5 Volt
-
Rated Current2 Ampere
-
Input Voltage90V~264V
-
Standards MetCCC,CE,EAC,FCC,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~50°C
-
Warranty2 Year
-
Length7.07 cm
-
Width4 cm
-
Height3.88 cm
-
Weight0.1 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the GE12I05-P1J for a 5V industrial controller or small automation module?
It is intended for constant voltage applications with a 5V output and up to 2A output current. That makes it a fit for 5V control electronics, embedded modules, or low-power automation devices that stay within the 10W rating.
Is this 5V power supply suitable for USB-powered embedded or IT equipment?
This model provides a regulated 5V constant voltage output with a 10W maximum power rating. It can be considered for 5V embedded or IT hardware that requires up to 2A and accepts an external AC-DC supply.
Can I use this adapter for a compact HMI, sensor hub, or edge device that runs on 5V?
It can support 5V equipment as long as the total load does not exceed 2A or 10W. The compact body size of 70.7 x 40.0 x 38.8 mm can also help where enclosure space is limited.
Is the GE12I05-P1J suitable for outdoor or harsh-environment use?
The listed operating temperature is -10°C to +50°C, but no IP rating is provided in the product specs. Based on the published data, it is better matched to environments within -10°C to +50°C where no outdoor or washdown protection rating is required.
How does the GE12I05-P1J compare with the other variants in this series?
The listed sibling variants are GE12I05-P1J-欧套, GE12I05-P1J-混套, GE12I05-P1J-澳套, GE12I05-P1J-美套, and GE12I05-P1J-英套. For this base model, the published specs are 10W, 5V, 2A, constant voltage, 90-264VAC input, and 70.7 x 40.0 x 38.8 mm dimensions.
