Mean Well GE12I15-P1J Power Supply 12W 15V
Please Login for Pricing
Description
Description
The GE12I15 is a 12W Mean Well power converter.
Key Features
- ✓ Protections: Overload / Over voltage
- ✓ Safety approvals: UL60950-1, CSA C22.2, TUV EN60950 -1, AS/NZS 60950.1, CCC GB4943
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesGE Series
-
Power Rating12 Watt
-
Output Voltage15 Volt
-
Rated Current0.8 Ampere
-
Input Voltage90V~264V
-
Standards MetCCC,CE,EAC,FCC,RCM,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~50°C
-
Warranty2 Year
-
Length7.07 cm
-
Width4 cm
-
Height3.88 cm
-
Weight0.1 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the GE12I15-P1J for a 15V industrial control device?
Yes, if the device requires constant 15V input and draws no more than 0.8A. This unit is rated for 12W total output, so it fits smaller 15V control devices within that limit.
Will this work for a 15V embedded system or evaluation platform?
It can work for embedded systems that need a regulated 15V constant voltage source up to 0.8A. The 90-264VAC input also supports use in facilities with different AC mains standards.
Is this a good fit for a 15V automation accessory or monitor module?
This model is appropriate for 15V automation accessories or monitor modules that stay within 12W and 0.8A. It is not a fit for loads that need a higher current than 0.8A.
How should I size this 15V power supply for my equipment?
Use it only with equipment designed for constant 15V input. The connected load must remain at or below 12W and 0.8A for proper sizing.
Can the GE12I15-P1J be used in outdoor or harsh-area conditions?
Its specified operating temperature range is -10°C to +50°C. Since no IP rating is provided, the product data supports use in indoor or otherwise protected environments rather than exposed outdoor locations.
Other GE12 Models
10 other models| Model | Power | Voltage | Current | |
|---|---|---|---|---|
| Mean Well NZ/AUS AC Inlet plug for GE12/18/24 Series | — | — | — | View |
| Mean Well GE12I24-P1J Power Supply 15W 24V | 15W | 24V | 0.62A | View |
| Mean Well GE12I12-P1J Power Supply 12W 12V | 12W | 12V | 1A | View |
| Mean Well EU AC Inlet plug for GE12/18/24 Series | — | — | — | View |
| Mean Well GE12I09-P1J Power Supply 12W 9V | 12W | 9V | 1.33A | View |
| Mean Well GE12I05-P1J Power Supply 10W 5V | 10W | 5V | 2A | View |
| Mean Well US AC Inlet plug for GE12/18/24 Series | — | — | — | View |
| Mean Well UK AC Inlet plug for GE12/18/24 Series | — | — | — | View |
| Mean Well GE12I18-P1J Power Supply 15W 18V | 15W | 18V | 0.83A | View |
| Mean Well GE12I07-P1J Power Supply 10W 7.5V | 10W | 7.5V | 1.33A | View |
