Mean Well HLG-150H-54AB Power Supply 150W 54V - Adjustable and Dimmable - Auckland, New Zealand Distributor

The HLG-150H is a 150W Mean Well AC-DC LED driver (input: 90~305VAC, output: 54V, operating temperature: -40~+90°C).

Key Features

✓ Input voltage: 90~305VAC
✓ Output voltage: 54V
✓ Rated output current: 2.8A
✓ Ingress protection: IP65
✓ Operating temperature: -40~+90°C
✓ Safety certifications: CB, CCC, CE, EAC, PSE, RCM, TÜV, UL
✓ 7 year warranty

Frequently Asked Questions

Can I use the HLG-150H-54AB with a building automation system to dim 54V LED fixtures?

Yes. The HLG-150H-54AB accepts 1-10V and PWM dimming signals, making it compatible with most building automation and smart lighting controllers. Combined with its built-in potentiometer for setting maximum output, you get both automated and manual brightness control for 54V LED fixtures.

Is the HLG-150H-54AB suitable for dimmable 54V LED warehouse lighting?

Yes. At 150W and 54V with dimming input and adjustable output, the HLG-150H-54AB is well suited for warehouse high-bay or aisle lighting where brightness needs to be reduced during off-peak hours. Its IP65 rating handles the dust common in warehouse environments.

Can the HLG-150H-54AB drive dimmable 54V LED horticultural lights?

Yes. The 1-10V/PWM dimming input lets you adjust light intensity for different growth stages, and the potentiometer allows fine-tuning the maximum drive current up to 2.8A at 54V. The constant-current CC range of 27-54V accommodates varying LED forward voltages in horticultural fixtures.

What dimming methods does the HLG-150H-54AB support?

The HLG-150H-54AB supports 1-10V analog dimming and PWM dimming signals. It also has a built-in potentiometer for manual output voltage and current adjustment. This combination allows compatibility with wall dimmers, automation controllers, and standalone manual trimming.

Is the HLG-150H-54AB rated for outdoor use under a canopy or soffit?

Yes. Its IP65 water-resistant rating protects against dust and low-pressure water jets, which is suitable for sheltered outdoor locations like canopies, soffits, or covered walkways. For fully exposed outdoor installations with direct rain, consider the IP67-rated HLG-150H-54B instead.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well HLG-150H-48 Power Supply 150W 48V 3.2A	150W	48V	3.2A	IP67	View
Mean Well HLG-150H-48B Power Supply 150W 48V- Dimmable 3.2A	150W	48V	3.2A	IP67	View
Mean Well HLG-150H-24 Power Supply 150W 24V 6.3A	150W	24V	6.3A	IP67	View
Mean Well HLG-150H-15A Power Supply 150W 15V - Adjustable 10A	150W	15V	10A	IP65	View
Mean Well HLG-150H-12 Power Supply 150W 12V 12.5A	150W	12V	12.5A	IP67	View
Mean Well HLG-150H-48A Power Supply 150W 48V - Adjustable 3.2A	150W	48V	3.2A	IP65	View
Mean Well HLG-150H-24A Power Supply 150W 24V - Adjustable 6.3A	150W	24V	6.3A	IP65	View
Mean Well HLG-150H-12A Power Supply 150W 12V - Adjustable 12.5A	150W	12V	12.5A	IP65	View
Mean Well S-HLG-150H-24 Power Supply 150W 24V with AU/NZ plug 6.3A	150W	24V	6.3A	IP67	View
