Description
Description
Features
Constant current mode output with multiple levels selectable by dip switch |
Emergency lighting application is available according to IEC61347-2-13 |
Built-in active PFC function and class II design |
Standby power consumption <0.5W |
Functions: DALI interface (logarithm or linear dimming curve selectable); push dimming synchronization up to 10 units |
3 years warranty |
General Specification
AC input voltage range | 180~295VAC; 254~392VDC |
AC inrush current (Typ.) | COLD START 20A(twidth=260μs measured at 50% Ipeak) at 230VAC; Per NEMA 410 |
Short circuit protection | Constant current limiting, recovers automatically after the fault condition is removed |
Over temperature protection | Shut down o/p voltage, re-power on to recover |
Setup time | 500ms / 230VAC |
Withstand voltage | I/P-O/P:3.75KVAC;I/P-DA:1.5KVAC; O/P-DA:1.5KVAC |
Working temperature | Tcase=-30 ~ +90℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section) |
Safety standards | UL8750(except for DA2-Type), CSA C22.2 No.250.13-12, ENEC BS EN/EN61347-1, BS EN/EN61347-2-13, BS EN/EN62384 independent, GB19510.14, GB19510.1, BIS IS15885(except for DA2-Type), EAC TP TC 004 approved; According to BS EN/EN61347-2-13 appendix J suitable for emergency installations |
EMC standards | EN55015, EN61000-3-2 class C, EN61000-3-3, EAC TP TC 020 |
Dimension (LxWxH)(mm) | 123.5*81.5*23mm |
Packing | 54pcs/15Kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesLCM Series
-
Power Rating40 Watt
-
Output Voltage65 Volt
-
Rated Current0.6 Ampere
-
Input Voltage180V~295V
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~90°C
-
Warranty3 Year
-
Length12.35 cm
-
Width8.15 cm
-
Height2.3 cm
-
Weight0.24 kg
