Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well MDD02L-05N SIP Package DC-DC Converter- 2W - ±5V out 37mA
Please Login for Pricing
Description
Description
Key Features
- ✓SIP7 package with international standard pinout
- ✓Operating temperature range -40 ~ +95°C
- ✓Comply with IEC/UL62368-1 (Expect for 15Vo/±15Vo) and LVD IEC60601-1
- ✓Medical safety approved (1xMOPP/2xMOOP) according to IEC60601-1
- ✓Low patient leakage current <2μA
- ✓Protections: Short circuit (Continuous)
- ✓6KVDC hight I/O isolation (Reinforced insulation)
- ✓Low cost
- ✓3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesMDD Series
-
Power Rating2 Watt
-
Output Voltage5 Volt
-
Rated Current0.03 Ampere
-
Input Voltage4.5V~5.5V
-
Standards MetCB,CE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~95°C
-
Warranty3 Year
-
Length1.97 cm
-
Width0.71 cm
-
Height1.15 cm
-
Weight0 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What kind of DC-DC converter is the Mean Well MDD02L-05N?
The MDD02L-05N is a 2W SIP-package DC-DC converter designed for compact board-level power conversion. This model provides a dual output of ±5V in a SIP7 form factor with reinforced 6KVDC input-to-output isolation.
What output does the MDD02L-05N provide?
This model is specified with a ±5V output and a 2W power rating. The product data also lists a rated current of 37 mA, making it suitable for low-power isolated DC-DC applications where a bipolar output is needed.
Is the MDD02L-05N suitable for medical or safety-sensitive equipment?
This converter is medical safety approved to IEC60601-1 with 1xMOPP and 2xMOOP noted in the product description. It also features low patient leakage current below 2μA and complies with IEC/UL62368-1, which makes it a strong fit for designs with strict isolation and safety requirements.
Can the MDD02L-05N be used in harsh temperature environments?
The MDD02L-05N is rated for operation from -40°C to +95°C. That wide temperature range makes it appropriate for industrial, embedded, and enclosed equipment that may face cold starts or elevated internal temperatures.
What protection and isolation features does the MDD02L-05N include?
This model includes continuous short-circuit protection and overload behavior that shuts down the output when rated power reaches 102% or more, then recovers automatically. It also provides 6KVDC input-to-output isolation with reinforced insulation for applications that need strong electrical separation.
How compact is the Mean Well MDD02L-05N?
The listed dimensions are 19.7 x 7.1 x 11.5 mm, and the product weight is 2.8 g. Its SIP7 package and small footprint make it a practical choice when PCB space is limited.
