Mean Well

Mean Well MPS-30-27 Power Supply 30W 27V 1.1A

SKU MPS-30-27
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
End of Life, Succeeded by RPS-30-27
Available to order
|

Overview

MPS-30-27 is the 27V output model of this series: rated current 1.1A, rated power 29.7W, typical efficiency 78%.

Features

  • Universal AC input / Full range
  • Low leakage current <200μA
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Medical safety approved (2 x MOPP between primary to secondary)
  • Fixed switching frequency at 100KHz
  • Low cost
  • High reliability
  • 3 years warranty

Specifications

MPS-30-27Specifications from the official datasheet (2021-09-15 edition)

OUTPUT

DC VOLTAGE
27V
RATED CURRENT
1.1A
CURRENT RANGE
0 ~ 1.1A
RATED POWER
29.7W
RIPPLE & NOISE (max.)Note.2
240mVp-p
VOLTAGE TOLERANCENote.3
±3.0%
LINE REGULATION
±0.5%
LOAD REGULATION
±1.0%
SETUP, RISE TIME
500ms, 30ms/230VAC 500ms, 30ms/115VAC at full load
HOLD UP TIME (Typ.)
70ms/230VAC 12ms/115VAC at full load

INPUT

VOLTAGE RANGE
88 ~ 264VAC auto switch 120 ~ 370VDC
FREQUENCY RANGE
47 ~ 63Hz
EFFICIENCY (Typ.)
78%
AC CURRENT (Typ.)
0.8A/115VAC 0.5A/230VAC
INRUSH CURRENT (Typ.)
COLD START 30A/230VAC
LEAKAGE CURRENT
Earth leakage current < 200μA/264VAC

PROTECTION

OVERLOAD
Above 105% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE
29.7 ~ 36.45V Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER TEMPERATURE
Shut down o/p voltage, re-power on to recover

ENVIRONMENT

WORKING TEMP.
-10 ~ +60℃ (Refer to "Derating Curve")
WORKING HUMIDITY
20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY
-20 ~ +85℃, 10 ~ 95% RH
TEMP. COEFFICIENT
±0.03%/℃ (0 ~ 50℃)
VIBRATION
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS
ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1 approved
ISOLATION LEVEL
Primary-Secondary: 2xMOPP, Primary-Earth:1xMOPP
WITHSTAND VOLTAGE
I/P-O/P:4KVAC I/P-FG:2KVAC O/P-FG:SHORT
ISOLATION RESISTANCE
I/P-O/P, I/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION
Compliance to EN55011 (CISPR11) Class B, EN61000-3-2,-3
EMC IMMUNITY
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN60601-1-2, medical level, criteria A

OTHERS

MTBF
547Khrs min. MIL-HDBK-217F (25℃)
DIMENSION
101.6*65.8*23.5mm (L*W*H)
PACKING
0.16Kg; 90pcs/15.8Kg/1.06CUFT
Test conditions and notes5
  1. 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
  2. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
  3. 3. Tolerance : includes set up tolerance, line regulation and load regulation.
  4. 4. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on a 360mm*360mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on http://www.meanwell.com)
  5. 5. When the input voltage is less than 40VAC, the SPS may exhibit degradation of performance. The final product manufacturers must re-confirm this deviation that does not affect basic safety or essential performance.

Technical drawings

MPS-30-27 Mechanical Specification
Mechanical Specification
MPS-30-27 Block Diagram
Block Diagram
MPS-30-27 Derating Curve
Derating Curve

Downloads

FAQ

Can I use the MPS-30-27 for a 27V industrial control or instrumentation load?

Yes, if the equipment requires constant-voltage 27V DC and draws no more than 1.1A. Its maximum output is 29.7W, so it fits lighter-duty 27V control and instrumentation applications.

Is this power supply suitable for a 27V embedded device or bench test assembly?

It can support a 27V embedded or test load when the total demand remains within 1.1A and 29.7W. The wide 88-264VAC input range also makes it practical for use across different AC supply regions.

Can the MPS-30-27 run a small 27V automation module continuously?

It is intended for constant-voltage 27V output and can power small automation modules that stay inside the 29.7W rating. Loads that need more than 1.1A would require a higher-capacity 27V power supply.

Is the MPS-30-27 meant for outdoor cabinets or exposed environments?

The product is specified for operation from -10°C to +60°C. No IP rating is listed, so the published specs do not indicate suitability for exposed outdoor use.

How does the MPS-30-27 differ from the other compact MPS output versions?

The related lower-power models are MPS-30-5 at 25W, 5V, 5A; MPS-30-12 at 30W, 12V, 2.5A; MPS-30-15 at 30W, 15V, 2A; MPS-30-24 at 28.8W, 24V, 1.2A; and MPS-30-48 at 28.8W, 48V, 0.6A. The MPS-30-27 version is rated at 29.7W, 27V, 1.1A.
