Mean Well MPS-30-48 Power Supply 30W 48V


|

Description

MEAN WELL MPS-30 Series Power Supplies are 30W singlel output medical type power supplies low cost ,high reliability with 3 years warranty.

Features

  • Universal AC input / Full range
  • Low leakage current <200pA
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Medical safety approved (2 x MOPP between primary to secondary)
  • Fixed switching frequency at 100KHz
  • Low cost
  • High reliability
  • 3 years warranty

Specifications

  • Brand
    Mean Well
  • Series
    MPS Series
  • Power Rating
    28.8 Watt
  • Output Voltage
    48 Volt
  • Rated Current
    0.6 Ampere
  • Input Voltage
    88V~264V
  • Standards Met
    CB,CE,TUV,UL
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -10°C~60°C
  • Warranty
    3 Year
  • Length
    10.16 cm
  • Width
    6.58 cm
  • Height
    2.35 cm
  • Weight
    0.16 kg

File Downloads

::specification::
