Mean Well MPS-65-3.3 Power Supply 65W 3.3V 12A

SKU MPS-65-3.3

Log in to see price Trade pricing & online ordering for account holders

End of Life, Succeeded by RPS-65-3.3

Available to order

Overview

MPS-65-3.3 is the 3.3V output model of this series: rated current 12A, rated power 39.6W, typical efficiency 66%.

Features

Universal AC input / Full range
Low leakage current <250μA
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Medical safety approved (2 x MOPP between primary to secondary)
100% full load burn-in test
Fixed switching frequency at 45KHz
3 years warranty

Specifications

MPS-65-3.3Specifications from the official datasheet (2021-09-15 edition)

OUTPUT

DC VOLTAGE: 3.3V
RATED CURRENT: 12A
CURRENT RANGE: 0 ~ 15.2A
RATED POWER: 39.6W
OUTPUT POWER (max.): 72W(+3.3V:50W;+5V:69W)with 18CFM min. Forced air convection
RIPPLE & NOISE (max.)^Note.2: 80mVp-p
VOLTAGE ADJ. RANGE: 2.97 ~ 3.63V
VOLTAGE TOLERANCE^Note.3: ±3.0%
LINE REGULATION: ±1.0%
LOAD REGULATION: ±3.0%
SETUP, RISE TIME: 800ms, 30ms/230VAC 800ms, 30ms/115VAC at full load
HOLD UP TIME (Typ.): 50ms/230VAC 16ms/115VAC at full load

INPUT

VOLTAGE RANGE: 90 ~ 264VAC 127 ~ 370VDC
FREQUENCY RANGE: 47 ~ 63Hz
EFFICIENCY(Typ.): 66%
AC CURRENT (Typ.): 1.6A/115VAC 0.9A/230VAC
INRUSH CURRENT (Typ.): COLD START 17A/115VAC 40A/230VAC
LEAKAGE CURRENT^Note.7: Earth leakage current < 250μA/264VAC , Touch current < 60μA/264VAC

PROTECTION

OVERLOAD: 73 ~ 105W (3.3V:51 ~ 75W)(5V:70 ~ 105W) rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE: 3.8 ~ 4.46V Protection type : Hiccup mode, recovers automatically after fault condition is removed

ENVIRONMENT

WORKING TEMP.: -10 ~ +60℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY: -20 ~ +85℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.04%/℃ (0 ~ 50℃)
VIBRATION: 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC (Note 4)

SAFETY STANDARDS: ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1 approved
ISOLATION LEVEL: Primary-Secondary: 2xMOPP, Primary-Earth:1xMOPP
WITHSTAND VOLTAGE: I/P-O/P:4KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to EN55011 (CISPR11) Class B, EN61000-3-2,-3
EMC IMMUNITY: Compliance to EN61000-4-2,3,4,5,6,8,11, EN60601-1-2, medical level, criteria A

OTHERS

MTBF: 359.7Khrs min. MIL-HDBK-217F (25℃)
DIMENSION: 127*76*42mm (L*W*H)
PACKING: 0.23Kg; 54pcs/14.6Kg/1.28CUFT

Test conditions and notes7

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on a 360mm*360mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on http://www.meanwell.com)
5. Mounting holes M1 and M2 should be grounded for EMI purposes.
6. Heat Sink HS1,HS2 can not be shorted.
7. Touch current was measured from primary input to DC output.

Technical drawings

MPS-65-3.3 Mechanical Specification — Mechanical Specification

MPS-65-3.3 Block Diagram — Block Diagram

MPS-65-3.3 Derating Curve — Derating Curve

Downloads

Catalogues1

Mean Well Catalog (Industrial) PDF Download

FAQ

Can I use the MPS-65-3.3 for 3.3V embedded controllers or logic boards?

Yes, if the electronics require constant 3.3V DC and the total current stays within 12A. This model is rated at 39.6W, which is substantial current for low-voltage digital loads. It should only be used with hardware specified for a 3.3V input rail.

Is the MPS-65-3.3 suitable for powering industrial computing or communication boards that run on 3.3V?

It can be a fit for industrial computing, communication, or processing boards designed around a 3.3V DC bus and drawing up to 12A. Because the output voltage is only 3.3V, exact voltage matching is critical. The supply operates from 90-264VAC input.

Can this model support low-voltage automation electronics with higher current demand?

It is better suited to low-voltage electronics that need more current rather than higher voltage, since it provides 3.3V at up to 12A. That can suit dense digital or embedded loads as long as the total power does not exceed 39.6W. It is not appropriate for 5V, 12V, 24V, or 48V systems.

How does the MPS-65-3.3 compare with the other MPS-65 models?

In the MPS-65 lineup, the available outputs are 3.3V 12A 39.6W, 5V 12A 60W, 7.5V 8A 60W, 12V 5.2A 62.4W, 13.5V 4.7A 63.45W, 15V 4.2A 63W, 24V 2.7A 64.8W, 27V 2.4A 64.8W, and 48V 1.35A 64.8W. This version is the lowest-voltage option and one of the highest-current outputs in the range. The correct choice depends on the exact DC voltage your electronics require.

Is the MPS-65-3.3 intended for indoor or outdoor conditions?

The product data specifies an operating temperature range of -10°C to +60°C. It does not provide an IP rating, so the listing does not indicate weather resistance or a sealed enclosure for outdoor exposure. On the stated specs alone, it is better considered for protected indoor use.
