Can I use the SPBW06F-03 to supply 3.3V logic in industrial or embedded equipment?

Yes, this converter is a constant voltage 3.3V model rated for 6W, which makes it suitable for low-power 3.3V logic and controller sections. The 9-36VAC input range also fits equipment that operates from a wide input range.

Is the SPBW06F-03 suitable for 3.3V communication or sensor modules in automation systems?

It can support low-power 3.3V modules because it provides 3.3V constant voltage output and 6W total power. Its compact 21.8 × 11.1 × 9.2 mm size is also useful in dense automation assemblies.

Can this model be used in compact IT or control hardware that needs a regulated 3.3V rail?

It is designed for constant voltage output at 3.3V and offers up to 6W, which fits regulated low-power rails in compact electronics. The small 0.0048 kg weight and small package help when size and mass matter.

Is the SPBW06F-03 rated for outdoor use or temperature extremes?

The operating temperature range is -40°C to +85°C, so the temperature specification covers demanding indoor environments and wide ambient variation. No IP rating is shown in the provided specs, so outdoor suitability is not specified.

How does the SPBW06F-03 compare with the other SPBW06F output options?

All listed SPBW06F models are 6W units with the same 9-36VAC input family. The SPBW06F-03 is 3.3V and 1.5A, the SPBW06F-05 is 5V and 1.2A, the SPBW06F-12 is 12V and 500A, and the SPBW06F-15 is 15V and 400A.

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well SPBW06F-03 DC-DC Converter - 6W - 9~36V in 3.3V out

SKU:

SPBW06F-03

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

Remote ON/OFF control

3 years warranty

Key Features

✓SIP8 package with industry-standard pinout
✓4:1 wide input range
✓Wide operating temperature range -40~+85°C
✓No minimum load required
✓High efficiency up to 89%
✓Protection: Short circuit(continuous)/Overload/Input under voltage
✓Comply to BS EN/EN55032 radiated Class B without additional components
✓1.5KVDC I/O isolation
✓Remote ON/OFF control
✓3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well SPBW06G-15 DC-DC Converter - 6W - 18~75V in 15V out	6W	15V	0.4A	Indoor	View
Mean Well SPBW06G-12 DC-DC Converter - 6W - 18~75V in 12V out	6W	12V	0.5A	Indoor	View
Mean Well SPBW06G-05 DC-DC Converter - 6W - 18~75V in 5V out	6W	5V	1.2A	Indoor	View
Mean Well SPBW06G-03 DC-DC Converter - 6W - 18~75V in 3.3V out	6W	3.3V	1.5A	Indoor	View
Mean Well SPBW06F-15 DC-DC Converter - 6W - 9~36V in 15V out	6W	15V	0.4A	Indoor	View
Mean Well SPBW06F-12 DC-DC Converter - 6W - 9~36V in 12V out	6W	12V	0.5A	Indoor	View
Mean Well SPBW06F-05 DC-DC Converter - 6W - 9~36V in 5V out	6W	5V	1.2A	Indoor	View
