Can I use the SRS-1215 to supply a 15V signal-conditioning stage in industrial controls?

It can fit a low-power 15V signal-conditioning or interface stage when your available source is 10-13VAC and the load stays within the unit's 0.5W, 0.03A output. This model is a constant-voltage converter, so it is intended for circuits that require a fixed 15V output rather than variable drive power.

Is the SRS-1215 suitable for a small embedded 15V bias rail?

Yes, it is suited to embedded or instrumentation circuits that need a light 15V auxiliary rail from a 10-13VAC source. The key limit is capacity: the output is 15V at 0.03A with a total power rating of 0.5W.

Can this converter power a low-current 15V analog module in an automation panel?

It is appropriate for a low-current 15V analog module if the module's demand does not exceed 0.03A and 0.5W. The compact 22.6 x 9.9 x 8.4 mm size also makes it easier to use where board or panel space is limited.

Would the SRS-1215 work for a compact 15V reference supply in test or monitoring equipment?

It can work for a compact 15V reference or support rail in monitoring equipment when the source is within 10-13VAC and the load is very small. The constant-voltage output and 0.5W rating make it better suited to light-duty control electronics than to higher-draw devices.

Is the SRS-1215 suitable for outdoor or harsh-environment use?

The published specs list an operating temperature range of -25C to +71C, but no IP rating is provided. That means the temperature range is defined, while outdoor exposure protection is not, so it is better treated as a component for protected indoor equipment or enclosed assemblies.

1 5

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well SRS-1215 DC-DC Converter - 0.5W - 10.8~13.2V in 15V out

SKU:

SRS-1215

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The SRS is a 0.5W Mean Well power converter.

Key Features

✓ 1KVDC reinforced I/O isolation
✓ Protections: Short circuit / Overload
✓ Safety approvals: WITHSTAND VOLTAGE ISOLATION RESISTANCE ISOLATION CAPACITANCE EMC EMISSION EMC IMMUNITY MTBF DIMENSION WEIGHT -25 ~ +105 ± 0.03% / ℃ ℃ , 10 ~ 95% RH ℃ ) (0 ~ 50 10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes EAC TP TC 004
✓ 3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well SRS-4815 DC-DC Converter - 0.5W - 43.2~52.8V in 15V out	0.5W	15V	0.03A	Indoor	View
Mean Well SRS-4812 DC-DC Converter - 0.5W - 43.2~52.8V in 12V out	0.5W	12V	0.04A	Indoor	View
Mean Well SRS-4809 DC-DC Converter - 0.5W - 43.2~52.8V in 9V out	0.5W	9V	0.05A	Indoor	View
Mean Well SRS-4805 DC-DC Converter - 0.5W - 43.2~52.8V in 5V out	0.5W	5V	0.1A	Indoor	View
Mean Well SRS-2415 DC-DC Converter - 0.5W - 21.6~26.4V in 15V out	0.5W	15V	0.03A	Indoor	View
Mean Well SRS-2412 DC-DC Converter - 0.5W - 21.6~26.4V in 12V out	0.5W	12V	0.04A	Indoor	View
Mean Well SRS-2409 DC-DC Converter - 0.5W - 21.6~26.4V in 9V out	0.5W	9V	0.05A	Indoor	View
Mean Well SRS-2405 DC-DC Converter - 0.5W - 21.6~26.4V in 5V out	0.5W	5V	0.1A	Indoor	View
Mean Well SRS-1212 DC-DC Converter - 0.5W - 10.8~13.2V in 12V out	0.5W	12V	0.04A	Indoor	View
Mean Well SRS-1209 DC-DC Converter - 0.5W - 10.8~13.2V in 9V out	0.5W	9V	0.05A	Indoor	View
Mean Well SRS-1205 DC-DC Converter - 0.5W - 10.8~13.2V in 5V out	0.5W	5V	0.1A	Indoor	View
Mean Well SRS-0515 DC-DC Converter - 0.5W - 4.5~5.5V in 15V out	0.5W	15V	0.03A	Indoor	View
Mean Well SRS-0512 DC-DC Converter - 0.5W - 4.5~5.5V in 12V out	0.5W	12V	0.04A	Indoor	View
Mean Well SRS-0509 DC-DC Converter - 0.5W - 4.5~5.5V in 9V out	0.5W	9V	0.05A	Indoor	View
Mean Well SRS-0505 DC-DC Converter - 0.5W - 4.5~5.5V in 5V out	0.5W	5V	0.1A	Indoor	View
