Description
Description
Features
Wide input range 100~305VAC(Class I) |
Full power output at 70~100% constant power mode operation |
Metal case with IP67, suitable for outdoor application |
Class 2 power unit(except for L type) |
Surge protection with 6KV/5KV |
3 in 1 dimming function (Dim to off and isolation design) |
India (EESL) version with Input Over Voltage Protection can survive input voltage stress of 440Vac for 48 hours |
Protection functions: OVP/SCP/OCP/OTP |
Lifetime > 50,000 hrs. and 5 years warranty |
General Specification
AC input voltage range | 100~305VAC;142~431VDC |
AC inrush current | Cold start, 50A at 230VAC |
DC adjustment range | ±10% rated output voltage |
Over-voltage protection | 108%~158% rated output voltage |
Setup, rise, hold up time | 500ms, 100ms, 12ms |
Withstand voltage | I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 1.5kVAC |
Working temperature | -40~+90°C |
Safety standards | UL8750 approved; .13-12;ENEC BS EN/EN61347-1; EAC TP TC 004;J61347-1(H29) |
EMC standards | EN55015, EN61000-3-2 class C,EN61000-3-3, EN61000-4-2,3,4,5,6,8,11 |
Dimension (LxWxH) | 140x63x32 |
Packing | 24pcs / 15kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesXLG Series
-
Power Rating60 Watt
-
Output Voltage12 Volt
-
Rated Current5 Ampere
-
Input Voltage100V~305V
-
Standards MetCB,CCC,CE,EAC,ENEC,RCM,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty5 Year
-
Length14 cm
-
Width6.3 cm
-
Height3.2 cm
-
Weight0.58 kg
