ENVO DALI2 Wall Panel, 2 Buttons, White
Log in to see priceOverview
Features
- DALI-2 control device with 2 push buttons according to IEC62386-101, IEC62386-103, IEC62386-301 and IEC62386-332
- Supports feedback functionality, provides 4 LEDs
- Suitable for integration and in combination with DALI-2 compliant central control units
- Multimaster capable, multiple modules can be installed on the DALI- line
- DALI bus powered, no extra power supply required
- Easy configuration via DALI-2 compliant central controller USB interface
- Compatible with universal 55mm frames
Specifications
DALI Interface
- Input Type
- DALI
- Marking
- DA
- Input Voltage Range
- 12VDC - 22.5VDC (according IEC62368-101)
- Typ. Current Consumption DALI (at 16.5V)
- 2mA
- Max. Current Consumption DALI (Inrush Current at 22.5V)
- 10mA
- Number of Addresses for DALI Control Devices
- 2
- Number of Feedback LED
- 4
General Data
- Dimensions (L x W x H)
- 71.2mm x 71.2mm x 11mm
- Mounting
- Wall Mounting or on Conduit Box
- Max. casing temperature Tc
- 75°C
- Expected Life Time @Tc
- 50,000H
- Protection Class
- II in Intended Use
- Protection Degree Housing
- IP20
- Protection Degree Terminals
- IP20
- Function
- Configurable
- Start-up Time
- <150ms
Terminals
- Connector Type
- Push-In
- Wire Size Solid Core
- 0.2 - 1.3 mm2 (AWG26 - AWG16)
- Wire Size Fine Core
- 0.2 - 1.3 mm2 (AWG26 - AWG16)
- Wire Size Using Wire End Ferrule
- 0.25 - 1.0 mm2
- Stripping Length
- 9 - 10 mm / 0.35 - 0.39 inch
- Release Connector
- Push Button
Environment Conditions
- Storing Temperature
- -20°C~+50°C
- Working Ambient Temperature
- -20°C~+50°C
- Relative Humidity
- 8%- 80%
Standards
- DALI
- IEC62386-101:2014 IEC62386-103:2014 IEC62386-301 IEC62386-332
- EMC
- EN 61547 EN 50015 / IEC CISPR15
- Safety
- EN 61347-2-11 EN 61347-1
Certifications & ratings
- Certification marks
- DALI-2, CE
Technical drawings
Downloads
Datasheet1
FAQ
What is the Sunricher SR-2422K2-DA2 used for?
The SR-2422K2-DA2 is a DALI2 wall panel intended for LED control system applications in commercial or professional environments. It is a 2-button white wall panel designed for use where a DALI2 control interface is required.
Is this wall panel compatible with DALI2 systems?
Yes. This model is identified as a DALI2 wall panel, so it is intended for use in DALI2-based lighting control systems. For buyers comparing options, the key compatibility point on this model is its DALI2 designation.
How many buttons does this wall panel have?
This model has 2 buttons. That makes it a straightforward choice for applications that need a compact DALI2 wall control interface without extra button positions.
What color and finish is the SR-2422K2-DA2?
The finish color for this model is white. That gives it a neutral appearance suited to many commercial and professional interior spaces.
What is the operating temperature range for this DALI2 wall panel?
The stated operating temperature range is -20 degrees C to 50 degrees C. This makes it suitable for indoor environments that stay within that temperature window.
What are the electrical and physical specs buyers should know?
This model has a typical current consumption of 2mA at 16.5V and a maximum inrush current of 10mA at 22.5V. It also includes an expected life time of 50,000 hours at Tc, which is useful for buyers evaluating lifecycle and maintenance expectations.
