Archilight Grid Mini 264C Track Light 8.5W - White + Gold

SKU:

KC-10.008A18-20D-2700-6000K-WG

Log in to see price Trade pricing & online ordering for account holders

Configure — 12 variants

KC-10.008A18-20D-2700-6000K-WG

LED Colour

Finish Colour

Beam Angle

12 matching

Pick options to narrow the list, or tap a row to select. Dimmed chips have no matching combination.

Product variants

Notify me when it's back in stock

Features:

Archilight Mini-series features a similar design to the Motion system. Being a lot smaller in size, the ultra-thin design is seen as a minimalist line, creating infinite visual effects yet the outstanding performance and function is maintained. This system is the best choice for a dedicated space where only the light itself attracts focus not the luminaire.

Archilight Dot Mini comes in different sizes, from 22 to 30mm in diameter. It also comes in different angles, colour and colour temperatures, covering all different scenarios. The light can also be rotated to create the best angle possible.

Pair It With:

Mini S Surface Tracks

Mini T Trimless Tracks

Mini O Suspended Tracks

Frequently Asked Questions

What is the Archilight Grid Mini 264C Track Light designed for?

The Archilight Grid Mini 264C is a compact micro magnetic track light module for interior spaces where a clean, minimal lighting look is important. Its slim Mini-series form factor is intended to keep attention on the light effect rather than the fitting itself. This makes it suitable for dedicated retail, hospitality, gallery, and other design-led indoor applications.

What beam angles are available across the Grid Mini 264C family?

This parent model is available in 20, 25, 38, and 60 degree beam angle variants. Narrower beams are better for more focused accent lighting, while wider beams suit broader illumination. The exact beam spread depends on the child variant selected.

What colour temperature options are offered for this track light?

Across the family, variants are available in 3000K and 4000K, with additional versions identified as 2700-6000K in the variant data. That gives buyers options for warmer, more neutral, or more flexible lighting preferences depending on the selected SKU. Colour temperature availability should be confirmed at the variant level before ordering.

What are the main performance specifications of the Archilight Grid Mini 264C?

The Grid Mini 264C is rated at 8.5W and delivers 671 lumens on the listed child variants. It also has a CRI of 90, which supports strong colour rendering in interior commercial and architectural spaces. Rated life is 50,000 hours and the warranty period is 5 years.

Is the driver included, and is this model dimmable?

No, the driver is not included with this product family. The listed variants also show dimming control as none, so this parent range should be treated as non-dimmable unless a specific project setup states otherwise. Buyers should account for separate driver requirements during product selection.

What system compatibility should I check before choosing this model?

This light is part of the Archilight Mini track system and is intended for use with matching Mini-series track formats. The product content specifically pairs it with Mini S Surface Tracks, Mini T Trimless Tracks, and Mini O Suspended Tracks. Compatibility should be checked against the track system family rather than assuming fit with other track ranges.

What are the physical dimensions of the Grid Mini 264C?

The parent model dimensions are 264 mm long, 100 mm wide, and 18 mm high, with a listed weight of 0.5 kg. These measurements make it a low-profile option within a compact architectural lighting layout. The slim body supports the minimalist visual effect described for the Mini series.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	CRI	Dimming	UGR
Archilight Grid R Mini 264C Track Light 8.5W - White + Gold	8.5W	90	None	19	View
Archilight Grid R Mini 264C Track Light 8.5W - White	8.5W	90	None	19	View
Archilight Grid R Mini 264C Track Light 8.5W - Black + Gold	8.5W	90	None	19	View
Archilight Grid R Mini 264C Track Light 8.5W - Black	8.5W	90	None	19	View
Archilight Grid Mini 264C Track Light 8.5W - White	8.5W	90	None	19	View
Archilight Grid Mini 264C Track Light 8.5W - Black + Gold	8.5W	90	None	19	View
Archilight Grid Mini 264C Track Light 8.5W - Black	8.5W	90	None	19	View
