Archilight Grid R Mini 264C Track Light 8.5W - White + Gold

SKU:

KC-10.009A18-20D-2700-6000K-WG

Log in to see price Trade pricing & online ordering for account holders

Configure — 12 variants

KC-10.009A18-20D-2700-6000K-WG

LED Colour

Finish Colour

Beam Angle

12 matching

Pick options to narrow the list, or tap a row to select. Dimmed chips have no matching combination.

Product variants

Notify me when it's back in stock

Features:

Archilight Mini-series features a similar design to the Motion system. Being a lot smaller in size, the ultra-thin design is seen as a minimalist line, creating infinite visual effects yet the outstanding performance and function is maintained. This system is the best choice for a dedicated space where only the light itself attracts focus not the luminaire.

Archilight Dot Mini comes in different sizes, from 22 to 30mm in diameter. It also comes in different angles, colour and colour temperatures, covering all different scenarios. The light can also be rotated to create the best angle possible.

Pair It With:

Mini S Surface Tracks

Mini T Trimless Tracks

Mini O Suspended Tracks

Frequently Asked Questions

What type of product is the Archilight Grid R Mini 264C?

The Archilight Grid R Mini 264C is a micro magnetic track light module designed for Archilight Mini-series track systems. It uses a slim linear form to keep the visual focus on the light effect rather than the fitting itself.

Which track systems is this light designed to pair with?

This model is intended to pair with Archilight Mini-series track options shown for the range, including Mini S Surface Tracks, Mini T Trimless Tracks, and Mini O Suspended Tracks. It is part of the mini magnetic track lighting family rather than a standalone luminaire.

What beam angle options are available across this product family?

The parent family is available in 20, 25, 38, and 60 degree beam angles. These options let buyers choose between narrower accent lighting and wider light distribution depending on the application.

What colour temperature options are offered in this family?

Variants in this family are offered in 3000K and 4000K, with some child variants also listed as 2700-6000K. That gives buyers options for warmer or more neutral lighting depending on the selected variant.

What are the main performance specifications of the Grid R Mini 264C?

This product family uses 8.5W of power and the listed child variants deliver 672 lumens. It also has a CRI of 90, making it suitable for applications where strong colour rendering is important.

Is the driver included, and is this track light dimmable?

The listed specification shows the driver is not included. The dimming control is listed as none, so this parent family should be treated as non-dimmable based on the provided data.

What are the physical dimensions of this parent model?

The parent model is listed as 264 mm long, 100 mm wide, and 18 mm high. Its weight is 0.5 kg, which supports use in slim, design-led interior track lighting layouts.

Is this track light suitable for long-term interior use?

Yes, the product is positioned for interior lighting applications and has a rated lifetime of 50,000 hours. It is also backed by a 5-year warranty, which is useful for commercial and specification-driven projects.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	CRI	Dimming	UGR
Archilight Grid R Mini 264C Track Light 8.5W - White	8.5W	90	None	19	View
Archilight Grid R Mini 264C Track Light 8.5W - Black + Gold	8.5W	90	None	19	View
Archilight Grid R Mini 264C Track Light 8.5W - Black	8.5W	90	None	19	View
Archilight Grid Mini 264C Track Light 8.5W - White + Gold	8.5W	90	None	19	View
Archilight Grid Mini 264C Track Light 8.5W - White	8.5W	90	None	19	View
Archilight Grid Mini 264C Track Light 8.5W - Black + Gold	8.5W	90	None	19	View
Archilight Grid Mini 264C Track Light 8.5W - Black	8.5W	90	None	19	View
