Archilight Grid R Mini 264C Track Light 8.5W - White
Log in to see priceTechnical drawings
Downloads
Datasheet1
Archilight Grid R Mini 264C Track Light 8.5W - White datasheetgrid_mini_264c_spec_sheet.pdf
PDF
Download
FAQ
What type of product is the Archilight Grid R Mini 264C?
The Archilight Grid R Mini 264C is a micro magnetic track light module designed for the Archilight Mini track system. It is part of a slim, minimalist interior lighting range intended to keep the focus on the light effect rather than the fitting itself.
What track systems is this light designed to pair with?
This model is intended to be paired with Archilight Mini track formats, including Mini S Surface Tracks, Mini T Trimless Tracks, and Mini O Suspended Tracks. It is a track light module for the Mini-series rather than a standalone general-purpose luminaire.
What are the key performance specifications of this track light family?
Across the family, the fitting is rated at 8.5W with a CRI of 90 and a stated lifetime of 50,000 hours. It also carries a 5-year warranty and uses 48V power input. Child variants listed here provide 672 lumens.
What beam angle options are available in this parent product family?
This parent family is available in 20 degree, 25 degree, 38 degree, and 60 degree beam angle options. That gives buyers a choice between narrower and wider light distribution depending on the application and desired focus.
What colour temperature options are available for this model?
The listed variants include fixed 3000K and 4000K options, plus versions identified as 2700-6000K. This means the family covers both warm and more neutral white choices, with additional variants that span a broader colour temperature range.
Is the driver included with the Archilight Grid R Mini 264C?
No, the parent product data states that the driver is not included. Buyers should account for that when specifying the full track lighting system.
Is this track light dimmable?
The supplied product data lists dimming control as none for this family. Based on the information provided, these variants should be treated as non-dimmable.
Where is this mini track light best suited?
This product is suited to interior spaces where a clean, low-profile lighting appearance is important. The Mini-series is described as a compact, ultra-thin system intended for dedicated spaces where the lighting effect takes visual priority over the luminaire itself.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other Archilight Grid 264 Series Models
7 other models| Model | Power | CRI | Dimming | UGR | |
|---|---|---|---|---|---|
| Archilight Grid R Mini 264C Track Light 8.5W - White + Gold | 8.5W | 90 | Non Dimmable | 19 | View |
| Archilight Grid R Mini 264C Track Light 8.5W - Black + Gold | 8.5W | 90 | Non Dimmable | 19 | View |
| Archilight Grid R Mini 264C Track Light 8.5W - Black | 8.5W | 90 | Non Dimmable | 19 | View |
| Archilight Grid Mini 264C Track Light 8.5W - White + Gold | 8.5W | 90 | Non Dimmable | 19 | View |
| Archilight Grid Mini 264C Track Light 8.5W - White | 8.5W | 90 | Non Dimmable | 19 | View |
| Archilight Grid Mini 264C Track Light 8.5W - Black + Gold | 8.5W | 90 | Non Dimmable | 19 | View |
| Archilight Grid Mini 264C Track Light 8.5W - Black | 8.5W | 90 | Non Dimmable | 19 | View |
