Hytronik Daylight Harvest PIR Sensor

400W, Microwave

SKU:

HCD038

Notify me when it's back in stock

Description

HC038V is a 1-10V control base whereas HCD038 and HCD038/P are DALI control bases with 30mA DALI power supply built in. They work with a wide range of microwave and PIR sensor heads. They are ideal for metal luminaire designs because the Bluetooth module is placed inside the sensor heads instead of control base, so that the Bluetooth signal transmission is viable. They are suitable for any typical indoor applications such as ofce, classroom, car park, warehouse and other commercial/industrial areas. With Bluetooth wireless mesh networking, it makes communication much easier without any hardwiring, which eventually adds values to luminaires and saves costs for projects. Meanwhile, simple device setup and commissioning can be done via Koolmesh app.

Specifications

Brand

Hytronik
Series

Hytronik
Power Rating

400 Watt
Standards Met

CB,CE,EMC,RCM,RED,SEMKO
Operating Temperature

-20°C~55°C
Warranty

5 Year
Length

12 cm
Width

3 cm
Height

2.1 cm
Weight

1 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What is the Hytronik HCD038 designed for?

The Hytronik HCD038 is a daylight harvest PIR sensor control base intended for indoor commercial and industrial lighting applications. It is suited to spaces such as offices, classrooms, car parks, and warehouses where automated lighting control can improve efficiency.

How does the HCD038 differ from the HC038V version?

The HCD038 is a DALI control base with a built-in 30mA DALI power supply. By comparison, the HC038V version is a 1-10V control base, so the HCD038 is the model to consider when DALI-based control is required.

What types of sensor heads can be used with the HCD038?

The HCD038 is designed to work with a wide range of microwave and PIR sensor heads. This gives specifiers flexibility when selecting the sensing approach for a particular indoor lighting application.

Is the HCD038 suitable for metal luminaire designs?

Yes. This model is described as ideal for metal luminaire designs because the Bluetooth module is placed inside the sensor heads rather than in the control base, helping maintain viable Bluetooth signal transmission.

What control and dimming features does the HCD038 support?

The HCD038 is a DALI control base and the product data lists tri-level dimming control. It is built for daylight harvesting and occupancy-based lighting strategies in smart commercial lighting systems.

Can the HCD038 be used in smart lighting systems?

Yes. The product supports Bluetooth wireless mesh networking, which helps simplify communication without hardwiring between devices. It is also compatible with setup and commissioning through the Koolmesh app.

What operating temperature range is specified for the HCD038?

The specified operating temperature range is -20°C to 55°C. That makes it suitable for a broad range of typical indoor commercial and industrial environments.

What are the key durability and load-related specs for the HCD038?

The HCD038 has a rated power of 400W, a listed lifetime of 50,000 hours, and a 5-year warranty. These specifications make it a practical option for professional projects that value service life and long-term reliability.
