Mean Well LPS-100-24 Power Supply 100W 24V
Please Login for Pricing
Description
Description
The LPS-100 is a 100W Mean Well power converter (input range: 88~132VAC).
Key Features
- ✓ Input voltage range: 88~132VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL60950-1, TUV EN60950-1
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesLPS Series
-
Power Rating100.8 Watt
-
Output Voltage24 Volt
-
Rated Current4.2 Ampere
-
Input Voltage88V~264V
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~60°C
-
Warranty2 Year
-
Length22.2 cm
-
Width6.2 cm
-
Height3.2 cm
-
Weight0.45 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the LPS-100-24 for 24V PLC I/O and industrial control devices?
Yes, this model is a constant voltage 24V supply with up to 4.2A output current. That makes it suitable for 24V control electronics, PLC-related loads, and panel devices that stay within its 100.8W rating.
Is the LPS-100-24 suitable for 24V automation sensors, relays, and actuators?
It can be used for 24V automation loads when the combined demand does not exceed 4.2A. Because it is a constant voltage unit, it is intended for equipment designed around a fixed 24V DC input.
Can this power supply run a 24V embedded or industrial communications device?
Yes, if the device requires 24V DC and its total draw stays within 100.8W. The 88-264VAC input range also supports deployment in facilities with different AC mains standards.
Is the LPS-100-24 a fit for compact 24V machine-control enclosures?
It is designed as a low-profile power supply measuring 222.0 x 62.0 x 32.0 mm and weighing 0.45 kg. Those dimensions can make it practical where a 24V, 4.2A source is needed inside a tighter enclosure footprint.
Can the LPS-100-24 be used outside or in wet locations?
The listed operating temperature is -10°C to +60°C, but the provided specifications do not include an IP rating. On the basis of the listed data, it is better suited to protected indoor equipment areas than directly exposed outdoor conditions.
Other LPS-100 Models
8 other models| Model | Power | Voltage | Current | |
|---|---|---|---|---|
| Mean Well LPS-100-7.5 Power Supply 100W 7.5V | 99.75W | 7.5V | 13.3A | View |
| Mean Well LPS-100-5 Power Supply 100W 5V | 100W | 5V | 20A | View |
| Mean Well LPS-100-48 Power Supply 100W 48V | 100.8W | 48V | 2.1A | View |
| Mean Well LPS-100-3.3 Power Supply 66W 3.3V | 66W | 3.3V | 20A | View |
| Mean Well LPS-100-27 Power Supply 102W 27V | 102.6W | 27V | 3.8A | View |
| Mean Well LPS-100-15 Power Supply 100W 15V | 100.5W | 15V | 6.7A | View |
| Mean Well LPS-100-13.5 Power Supply 101W 13.5V | 101.25W | 13.5V | 7.5A | View |
| Mean Well LPS-100-12 Power Supply 100W 12V | 100.8W | 12V | 8.4A | View |
