Mean Well LPS-100-27 Power Supply 102W 27V
Please Login for Pricing
Description
Description
The LPS-100 is a 100W Mean Well power converter (input range: 88~132VAC).
Key Features
- ✓ Input voltage range: 88~132VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL60950-1, TUV EN60950-1
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesLPS Series
-
Power Rating102.6 Watt
-
Output Voltage27 Volt
-
Rated Current3.8 Ampere
-
Input Voltage88V~264V
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~60°C
-
Warranty2 Year
-
Length22.2 cm
-
Width6.2 cm
-
Height3.2 cm
-
Weight0.45 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the LPS-100-27 for 27V industrial control or communications equipment?
Yes, if the equipment is designed for a 27V constant voltage input and draws no more than 3.8A. This model provides up to 102.6W, which fits many 27V control and communications loads within that current range.
Is the LPS-100-27 suitable for 27V embedded systems and interface hardware?
It can be suitable when the hardware expects a fixed 27V supply and stays below 102.6W total output. Its constant voltage operation is aligned with electronics that need a regulated DC rail rather than a constant current source.
Can this model power 27V automation modules in a compact cabinet?
Yes, for 27V automation modules whose combined load is within 3.8A. The 222.0 x 62.0 x 32.0 mm dimensions and 0.45 kg weight make it easier to consider in slimmer control assemblies.
Is the LPS-100-27 appropriate for equipment used across different AC input regions?
It accepts 88-264VAC input, so it can support equipment builds that need the same DC output from a broad AC input range. On the output side, it remains a 27V constant voltage supply rated for 3.8A.
What environments is the LPS-100-27 best matched for?
The provided operating temperature range is -10°C to +60°C, which defines the listed thermal conditions. Because no IP rating is provided in the specs, the safest fit from the available data is protected indoor equipment use rather than outdoor exposure.
Other LPS-100 Models
8 other models| Model | Power | Voltage | Current | |
|---|---|---|---|---|
| Mean Well LPS-100-24 Power Supply 100W 24V | 100.8W | 24V | 4.2A | View |
| Mean Well LPS-100-7.5 Power Supply 100W 7.5V | 99.75W | 7.5V | 13.3A | View |
| Mean Well LPS-100-5 Power Supply 100W 5V | 100W | 5V | 20A | View |
| Mean Well LPS-100-48 Power Supply 100W 48V | 100.8W | 48V | 2.1A | View |
| Mean Well LPS-100-3.3 Power Supply 66W 3.3V | 66W | 3.3V | 20A | View |
| Mean Well LPS-100-15 Power Supply 100W 15V | 100.5W | 15V | 6.7A | View |
| Mean Well LPS-100-13.5 Power Supply 101W 13.5V | 101.25W | 13.5V | 7.5A | View |
| Mean Well LPS-100-12 Power Supply 100W 12V | 100.8W | 12V | 8.4A | View |
