Mean Well SCWN06A-05 DC-DC Converter - 6W 9~18V DC in 5V out 1A
Please Login for Pricing
Description
Description
The SCWN06A is a 6W Mean Well power converter (input range: 9~18Vdc, operating temperature: -40~+100℃).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSCWN Series
-
Power Rating6 Watt
-
Output Voltage5 Volt
-
Rated Current1 Ampere
-
Input Voltage9V~18V
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length3.18 cm
-
Width2.03 cm
-
Height1.02 cm
-
Weight0.01 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SCWN06A-05 to power a 5V microcontroller or embedded control board from a 12V system?
Yes, this model is intended for constant-voltage 5V output and accepts a 9-18VAC input range, which fits many nominal 12V control systems. It can supply up to 1A with a 6W maximum output, so the total 5V load needs to stay within those limits.
Is the SCWN06A-05 suitable for 5V industrial sensors or small logic modules in a control cabinet?
It can be a fit for low-power 5V sensors, logic boards, or interface electronics that require regulated 5V. The key limits are the 1A maximum output current, 6W power rating, and 9-18VAC input range.
Can this converter be used in embedded or automation equipment where space is limited?
Yes, it is compact at 31.8 x 20.3 x 10.2 mm and weighs 0.0125 kg, which helps in tightly packed embedded assemblies. Electrically, it is best suited to small 5V loads that remain within 1A and 6W.
Would the SCWN06A-05 work for a small 5V communications or monitoring board in industrial equipment?
It can work for low-power 5V monitoring, controller, or communications boards when the source is within 9-18VAC. Because the output is fixed at 5V constant voltage and limited to 1A, it is not intended for higher-current 5V devices.
What is the difference between the SCWN06A-05 and the other SCWN06A models?
All SCWN06A models in this group are 6W converters with the same 9-18VAC input range. The difference is the output: SCWN06A-03 is 3.3V at 1.2A, SCWN06A-05 is 5V at 1A, SCWN06A-12 is 12V at 0.5A, and SCWN06A-15 is 15V at 0.4A.
Is the SCWN06A-05 suitable for outdoor or harsh-temperature environments?
The specified operating temperature is -40°C to +90°C, so the temperature range is broad. However, no IP rating is listed, so exposed outdoor or washdown use is not established from the provided specs.
