Mean Well SCWN06B-03 DC-DC Converter - 6W 18~36V DC in 3.3V out 1.2A
Please Login for Pricing
Description
Description
The SCWN06B is a 6W Mean Well power converter (input range: 9~18Vdc, operating temperature: -40~+100℃).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSCWN Series
-
Power Rating6 Watt
-
Output Voltage3.3 Volt
-
Rated Current1.2 Ampere
-
Input Voltage18V~36V
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length3.18 cm
-
Width2.03 cm
-
Height1.02 cm
-
Weight0.01 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SCWN06B-03 to derive 3.3V logic power from a 24V or 36V control system?
Yes, this model accepts 18-36VAC input and provides a constant-voltage 3.3V output, which aligns with many 24V and 36V control environments. It can deliver up to 1.2A with a 6W maximum output.
Is the SCWN06B-03 suitable for powering embedded processors or 3.3V communication electronics in automation equipment?
It can be a fit for low-power 3.3V embedded boards, control logic, or communications modules that stay within 1.2A and 6W. The 18-36VAC input range makes it more appropriate for higher-voltage control systems than the A-series input range.
Would the SCWN06B-03 work for 3.3V PLC-adjacent electronics inside an industrial panel?
It is suitable for 3.3V support electronics when the available source falls within 18-36VAC and the load remains within the 1.2A limit. The compact 31.8 x 20.3 x 10.2 mm size also supports use in dense panel layouts.
Can this converter support a low-power 3.3V monitoring or interface board from a higher-voltage DC bus?
It is designed for that type of low-power conversion, provided the source is in the 18-36VAC range and the output demand does not exceed 6W. Since the output is fixed at 3.3V constant voltage, it fits electronics built for a regulated 3.3V rail.
How does the SCWN06B-03 compare with the other SCWN06B models?
All SCWN06B versions share a 6W rating and the same 18-36VAC input range. The outputs differ by SKU: SCWN06B-03 is 3.3V at 1.2A, SCWN06B-05 is 5V at 1A, SCWN06B-12 is 12V at 0.5A, and SCWN06B-15 is 15V at 0.4A.
Is the SCWN06B-03 suitable for outdoor cabinets or wide-temperature installations?
The operating temperature range is listed as -40°C to +90°C, which supports use across a wide temperature span. No IP rating is shown, so the specs do not establish outdoor-exposed or water-resistant use.
