Mean Well SCWN06A-12 DC-DC Converter - 6W 9~18V DC in 12V out 500mA
Please Login for Pricing
Description
Description
The SCWN06A is a 6W Mean Well power converter (input range: 9~18Vdc, operating temperature: -40~+100℃).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSCWN Series
-
Power Rating6 Watt
-
Output Voltage12 Volt
-
Rated Current0.5 Ampere
-
Input Voltage9V~18V
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length3.18 cm
-
Width2.03 cm
-
Height1.02 cm
-
Weight0.01 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SCWN06A-12 to run a 12V control circuit from a nominal 12V input source?
This converter accepts 9-18VAC input and provides a constant-voltage 12V output. It is appropriate for low-power 12V control electronics as long as the load stays within 0.5A and 6W.
Is the SCWN06A-12 a good fit for 12V automation sensors or small interface modules?
It can be used for 12V automation or interface devices that need regulated constant-voltage output. The important limits are 12V output, 0.5A maximum output current, and 6W total output power.
Can this model power a compact 12V monitoring or signaling board in industrial equipment?
Yes, if the board requires 12V and remains under 0.5A, this model fits that type of low-power application. Its 31.8 x 20.3 x 10.2 mm size and 0.0125 kg weight also make it practical in compact equipment.
Would the SCWN06A-12 be suitable for low-power 12V electronics inside embedded systems?
It is intended for small constant-voltage 12V loads in systems with a 9-18VAC input source. Because the output ceiling is 0.5A and 6W, it is better suited to control, sensing, or signaling electronics than heavier 12V loads.
How does the SCWN06A-12 compare with the other SCWN06A versions?
The SCWN06A family shares the same 6W power rating and 9-18VAC input range. Output options are 3.3V at 1.2A for SCWN06A-03, 5V at 1A for SCWN06A-05, 12V at 0.5A for SCWN06A-12, and 15V at 0.4A for SCWN06A-15.
Can the SCWN06A-12 be used in hot or cold industrial enclosures?
The operating temperature range is -40°C to +90°C, which supports use across very low and very high ambient temperatures. No IP rating is provided, so the specs do not confirm suitability for exposed outdoor environments.
