Mean Well SCWN06C-05 DC-DC Converter - 6W 36~72V DC in 5V out 1A
Please Login for Pricing
Description
Description
The SCWN06C is a 6W Mean Well power converter (input range: 9~18Vdc, operating temperature: -40~+100℃).
Key Features
- ✓ Input voltage range: 9~18Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+100℃
- ✓ Protections: Short circuit / Overload / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSCWN Series
-
Power Rating6 Watt
-
Output Voltage5 Volt
-
Rated Current1 Ampere
-
Input Voltage36V~72V
-
Standards MetCE,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length3.18 cm
-
Width2.03 cm
-
Height1.02 cm
-
Weight0.01 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the SCWN06C-05 for 5V control electronics on a 48V or 60V DC platform?
Yes, this converter accepts 36-72V input and provides constant 5V output. Its 6W rating and 1A output current make it suitable for low-power 5V control electronics, logic devices, and interface circuits.
Is the SCWN06C-05 suitable for powering a 5V embedded processor or communication module?
It is a fit when the 5V load stays within 1A and the total output stays within 6W. That aligns well with many embedded processors, communication modules, and low-power digital subsystems.
Can this model be used for 5V USB-class electronics inside industrial equipment?
It can be used for 5V electronics that need a regulated 5V rail from a 36-72V source, provided the load does not exceed 1A. The output class is better suited to low-power electronics than to larger 5V devices with higher current demand.
How does the SCWN06C-05 differ from other SCWN06C family models?
The family shares the same 6W rating and 36-72V input range, but each model has a different output. The SCWN06C-03 is 3.3V at 1.2A, the SCWN06C-05 is 5V at 1A, the SCWN06C-12 is 12V at 0.5A, and the SCWN06C-15 is 15V at 0.4A.
Can the SCWN06C-05 handle high-temperature or outdoor environments?
The converter is rated for -40°C to +90°C operation, so the temperature range supports demanding equipment conditions. Because no IP rating is provided, the listed specs do not by themselves support direct outdoor or exposed-environment use.
