Mean Well XLG-150-L-A AC-DC Single output LED driver Constant Power Mode 150W

The XLG-150-L-A is a high-voltage constant-current driver rated at 150W with a 214V output and 1.05A current. It is intended for long LED module strings or high-voltage LED arrays such as streetlight modules and large luminaires that operate in the 100–214V range rather than low-voltage LED strips.

Yes. The XLG-150-L-A is rated IP67, meaning it is sealed against dust and can withstand temporary water immersion. This makes it suitable for installation inside outdoor streetlight housings, area light enclosures, and other weatherproof luminaire bodies.

Yes. Its 150W constant-current output at 1.05A and high output voltage range up to 214V matches the electrical requirements of many LED streetlight modules. The IP67 enclosure, -40°C to +90°C operating range, and wide 100–305VAC input make it a practical fit for roadway lighting applications.

Yes. High-bay luminaires that use series-connected LED arrays in the 100–214V range are compatible with the XLG-150-L-A's output. The driver's 150W capacity and IP67 rating support both the high ambient temperatures and any moisture exposure common in industrial environments.

The XLG-150-L-A outputs 150W at 214V / 1.05A and is designed for high-voltage LED arrays. The XLG-150-24-A outputs 150W at 24V / 6.25A and is designed for low-voltage LED strips and signage. Both share IP67 protection and the same 100–305VAC input range, but they serve fundamentally different LED load types.

Yes. The 100–305VAC wide-range input covers both 120V and 277V systems commonly found in North American commercial and industrial buildings, as well as 230V supplies used internationally. No manual voltage switching is required.
