iLLUMAX LED Strip ULTRA+ Series 204LEDs/m 24.5W/m 24V

SKU:

3014-2042400SCX-CW

Log in to see price Trade pricing & online ordering for account holders

Configure — 6 variants

3014-2042400SCX-CW

Length

LED Colour

6 matching

Pick options to narrow the list, or tap a row to select. Dimmed chips have no matching combination.

Product variants

Notify me when it's back in stock

Specifications:

Power Rating: 24.5W/m
Input Voltage: 24V DC
LED Density: 204 LEDs/m
Cutting Length: 29.4mm
Beaming Angle: 120 Degree
Width: 10mm
Lifetime: 50000hrs
Mounting: Standard: 3M Tape

Frequently Asked Questions

What are the main specifications of the Archilight LED Strip ULTRA+ Series 24V strip?

This LED strip is rated at 24.5W per metre and operates on 24V DC. It has a density of 204 LEDs per metre, a 120 degree beam angle, and a cutting length of 29.4mm. The listed lifetime is 50,000 hours and the standard mounting option is 3M tape.

What light colour options are available in this LED strip family?

This parent family is available in three colour temperature options: 3000K, 4000K, and 6000K. These correspond to warm white, neutral white, and cool white style outputs. The core electrical and output specifications remain the same across the variants shown.

Is the driver included with this LED strip?

No, the driver is not included with this product family. The strip is specified for 24V DC input, so buyers should account for a separate compatible driver when planning the product selection. This applies across the variants listed for this parent model.

Is this LED strip dimmable?

Yes, this product family is listed as dimmable with optional dimming control. That means dimming capability is supported, but any required dimming accessories or controls are not indicated as included with the strip. The dimming status is consistent across the child variants provided.

How bright is this LED strip?

The child variants in this family are listed at 2100 lumens. That gives buyers a high-output strip option paired with a dense 204 LEDs per metre layout for a more continuous lighting appearance. The brightness value shown is the same across the listed colour temperature variants.

What types of projects is this LED strip suitable for?

This strip is suited to indoor linear lighting applications where a 24V, high-density LED strip is needed for consistent light output. Its 204 LEDs per metre spacing and 120 degree beam angle make it relevant for commercial and architectural-style lighting use. Buyers comparing options in this family will mainly choose based on preferred colour temperature rather than major spec changes.

What warranty is offered for this LED strip family?

The listed warranty period for this product family is 2 years. The same warranty period appears across the child variants provided. This makes the warranty position consistent regardless of the selected colour temperature option.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	LED Density	Cuttable	IP Rating
iLLUMAX LED Strip ULTRA Series 120LEDs/m 14.4W/m 24V	14.4W	120LEDs/m	50mm	Indoor	View
iLLUMAX LED Strip ARCH Series 120LEDs/m 9.6W/m 24V - CRI>90	9.6W	120LEDs/m	50mm	Indoor	View
ILLUMAX LED Strip RAINBOW Series 60LEDs/m 14.4W/m 12V - Waterproof - 5m Reel	14.4W	60LEDs/m	50mm	—	View
iLLUMAX LED Strip ULTRA Series 120LEDs/m 14.4W/m 24V - Waterproof - 5m Reel	72W	—	50mm	IP68	View
iLLUMAX LED Strip RAINBOW Series 60LEDs/m 14.4W/m 12V	14.4W	60LEDs/m	50mm	Indoor	View
iLLUMAX LED Strip Basic Series 60LEDs/m 4.8W/m 12V	4.8W	60LEDs/m	50mm	Indoor	View
iLLUMAX LED Strip RAINBOW Series 30LEDs/m 7.2W/m 12V	7.2W	30LEDs/m	100mm	Indoor	View
iLLUMAX LED Strip ARCH+ Series 240LEDs/m 19.2W/m 24V - CRI>90	19.2W	120LEDs/m	25mm	Indoor	View
