Mean Well HEP-320-48A Power Supply - Best Stock Availability & Prices

Overview

HEP-320-48A is the 48V output model of this series: rated current 6.7A, rated power 321.6W, typical efficiency 94.5%.

HEP-320 is a 320W industrial AC/DC power supply featuring the outstanding capability to operate under a harsh environment with high dust density, humidity, vibration and altitude. The entire series is housed with a robust aluminum case and fully potted with heat-conducted silicone. Thanks to state-of-the-art design, the working efficiency is up to 95%, enabling HEP-320, with a fanless design, perfectly work between -55℃ and +70℃ under free air convection.

Features

Universal AC input / Full range
Built-in active PFC function
High efficiency up to 95%
Fanless design, cooling by free air convection
-55~+70℃ wide operating range
Aluminum case and filling with heat-conducted silicone
IP65 design, optional IP68 rated model available
Meet 6KV surge immunity level
Withstand 10G vibration test
Operating altitude up to 5000 meters (Note.8)
Protections: Short circuit / Overload / Over voltage / Over temperature
6 years warranty

Specifications

HEP-320-48ASpecifications from the official datasheet (2025-10-10 edition)

OUTPUT

DC VOLTAGE: 48V
RATED CURRENT: 6.7A
RATED POWER: 321.6W
RIPPLE & NOISE (max.)^Note.2: 250mVp-p
VOLTAGE ADJ. RANGE^Note.5: 43 ~ 52V
CURRENT ADJ. RANGE^Note.5: 3.35 ~ 6.7A
VOLTAGE TOLERANCE^Note.3: ±1.0%
LINE REGULATION: ±0.5%
LOAD REGULATION: ±0.5%
SETUP, RISE TIME^Note.6: 2500ms,80ms/115VAC 600ms,80ms/230VAC at full load
HOLD UP TIME (Typ.): 15ms at full load 230VAC /115VAC

INPUT

VOLTAGE RANGE^Note.4: 90~264VAC (277VAC operational) 128~370VDC(390VDC operational)
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ.): PF>0.98/115VAC, PF>0.95/230VAC, PF>0.94/277VAC at full load
EFFICIENCY (Typ.): 94.5%
AC CURRENT (Typ.): 3.5A / 115VAC 1.65A / 230VAC 1.45A / 277VAC
INRUSH CURRENT(Typ.): COLD START 70A at 230VAC
LEAKAGE CURRENT: <0.75mA / 277VAC

PROTECTION

OVER CURRENT: 105 ~ 125% Protection type : Hiccup mode, recovers automatically after fault condition is removed
SHORT CIRCUIT: Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE: 53.5 ~ 60V Protection type : Shut down and latch off o/p voltage, re-power on to recover
OVER TEMPERATURE: Shut down and latch off o/p voltage, re-power on to recover

ENVIRONMENT

WORKING TEMP.: -55 ~ +70℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -60 ~ +80℃, 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 60℃)
VIBRATION: 20 ~ 500Hz, 10G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS^Note.8: UL62368-1,IEC62368-1, IP65 (or IP68 for HEP-320 Blank-Type), EAC TP TC 004 approved ; Design refer to BS EN/EN62368-1
WITHSTAND VOLTAGE: I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
EMC IMMUNITY: Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, light industry level (surge 6KV), EAC TP TC 020

OTHERS

MTBF: 1565.6K hrs min. Telcordia SR-332 (Bellcore) ; 154.2Khrs min. MIL-HDBK-217F (25℃)
DIMENSION: 252*90*43.8mm (L*W*H)
PACKING: 1.88Kg; 8pcs/16Kg/0.92CUFT

Certifications & ratings

IP rating: IP65 IP68 (Optional)

Test conditions and notes9

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Derating may be needed under low input voltages. Please check the static characteristics for more details.
5. A-type only.
6. Length of set up time is measured at cold first start. Turning ON/OFF the power supply may lead to increase of the set up time.
7. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
8. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
9. The water protection level test for the IP68 rating is performed 1000mm below the surface of the water for 1 month.

Technical drawings

HEP-320-48A Block Diagram — Block Diagram

HEP-320-48A Derating Curve — Derating Curve

HEP-320-48A Mechanical Specification — Mechanical Specification

Typical applications

Outdoor telecommunication equipment
Outdoor electronic signage and billboard
Petroleum plant or mine shaft facility

Downloads

Certificates5

Mean Well HEP-EAC Certificate PDF Download

Mean Well HEP-320-CB(UL) Certificate PDF Download

Mean Well HEP-320-EMC Certificate PDF Download

Mean Well HEP-320-CE-dec Certificate PDF Download

Mean Well HEP-320-UK-dec Certificate PDF Download

Test reports1

Mean Well HEP-320-48 Test Report PDF Download

Catalogues1

Mean Well Catalog (Industrial) PDF Download

FAQ

Can I use the HEP-320-48A for 48V DC telecom or control equipment?

Yes, this supply delivers constant 48V output up to 6.7A and 321.6W for equipment designed around a 48VDC input. It is appropriate for telecom, control, and industrial electronics that operate within those electrical limits. The 90-264VAC input range (277VAC operational) is also useful where incoming AC supply varies by site.

Is the HEP-320-48A suitable for 48V industrial networking or embedded systems?

It can be used for 48V networking or embedded equipment that requires a regulated constant-voltage source and draws no more than 321.6W or 6.7A. The fanless design helps reduce maintenance in enclosed or dusty environments. Its IP65 rating is intended for harsher service conditions than a standard indoor supply.

Can this model be used in automation equipment exposed to vibration or temperature extremes?

It is designed for harsh environments, with 10G vibration resistance and an operating range of -55°C to +70°C. That makes it suitable for automation and industrial equipment housings where shock, vibration, or temperature swing matters. The constant-voltage 48V output still needs to match the equipment requirement.

Is the HEP-320-48A suitable for outdoor use?

This version has an IP65 water-resistant enclosure, so it is suitable for demanding indoor locations and sheltered outdoor environments where dust and water spray are present. It is not the higher-IP option in the series. The temperature rating remains -55°C to +70°C.

How does the HEP-320-48A differ from the other HEP-320 models?

In the HEP-320 range, the available outputs are 264W at 12V 22A for HEP-320-12 and HEP-320-12A, 285W at 15V 19A for HEP-320-15 and HEP-320-15A, 320.16W at 24V 13.34A for HEP-320-24 and HEP-320-24A, 320.4W at 36V 8.9A for HEP-320-36 and HEP-320-36A, 321.6W at 48V 6.7A for HEP-320-48 and HEP-320-48A, and 321.3W at 54V 5.95A for HEP-320-54 and HEP-320-54A. Selection comes down to matching the required DC voltage and current to the load while staying within the model's rated wattage.
