Mean Well LPV-100-24 LED Driver — 100.8W 24V 4.2A IP67 Waterproof

Constant Voltage, CE/EAC/UL Certified, 90-264VAC Universal Input, 2-Year Warranty

SKU:

LPV-100-24

Model

20W 24V

SKU: LPV-20-24

100W 24V

SKU: LPV-100-24

35W 24V

SKU: LPV-35-24

60W 24V

SKU: LPV-60-24

150W 24V

SKU: LPVL-150-24

Product variants

Please for Pricing

Notify me when it's back in stock

Description

Mean Well LPV-100-24 LED Driver — 100.8W 24V 4.2A IP67 Waterproof

The Mean Well LPV-100-24 is a 100.8W, 24V constant voltage LED driver with IP67 waterproof protection, engineered for reliable performance in demanding indoor and outdoor LED lighting applications. Built to Mean Well's industry-leading quality standards, it delivers stable 24V DC output at up to 4.2A and carries CE, EAC, UL certifications for global compliance.

Accepting 90-264VAC universal AC input, the LPV-100-24 operates reliably across a wide supply range. It features built-in short circuit, overload, and over-voltage protection to safeguard connected LED loads, and is rated for operation from -25°C to +70°C making it suitable for outdoor and harsh-environment installations.

Key Features

Constant voltage output: 24V DC at up to 4.2A (100.8W max)
IP67 waterproof and dustproof — suitable for outdoor installations
Universal AC input: 90-264VAC
Certifications: CE, EAC, UL
Wide operating temperature: -25°C to +70°C
Built-in protections: short circuit, overload, over-voltage
Compact, lightweight enclosure: 190.0 × 52.0 × 37.0 mm, 0.63 kg
2-year Mean Well warranty

Specifications

Model	LPV-100-24
Output Power	100.8W
Output Voltage	24V DC
Output Current	4.2A
Operation Mode	Constant Voltage
Input Voltage Range	90-264VAC
IP Rating	IP67 Waterproof
Certifications	CE, EAC, UL
Operating Temperature	-25°C to +70°C
Dimensions (L × W × H)	190.0 × 52.0 × 37.0 mm
Weight	0.63 kg
Warranty	2 Years

Applications

LED signage and electronic displays
Architectural and decorative LED lighting
Outdoor and landscape LED installations
Stage and theater LED lighting
Commercial LED lighting installations

Specifications

Brand

Mean Well
Series

LP Series
Power Rating

100.8 Watt
Output Voltage

24 Volt
Rated Current

4.2 Ampere
Input Voltage

90V~264V
Standards Met

CE,EAC,UL
Operation Mode

Constant Voltage
Operating Temperature

-25°C~70°C
Warranty

2 Year
Length

19 cm
Width

5.2 cm
Height

3.7 cm
Weight

0.63 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What LED strip voltage does the LPV-100-24 support?

The LPV-100-24 provides a constant 24V DC output, making it directly compatible with 24V LED strip lights, 24V LED panel systems, and 24V architectural lighting fixtures. It cannot be used to power 12V strips without an additional regulator.

How long a run of 24V LED strip can the LPV-100-24 drive?

The LPV-100-24 outputs 100.8W at 24V. Divide 100.8W by your strip's wattage per meter — a common 24V strip at 9.6 W/m allows up to about 10.5 meters, and a 14.4 W/m high-output strip allows roughly 7 meters. Confirm the rated power per meter for your specific strip before committing to a run length.

Is the LPV-100-24 suitable for outdoor signage applications?

Yes. Its IP67 rating provides full dust ingress protection and resistance to temporary water immersion, making it appropriate for covered outdoor channel-letter signs, building facade lighting, and exterior display cases running 24V LED modules.

Does the LPV-100-24 work on 277V commercial mains?

No. The LPV-100-24 accepts 90–264 VAC. A 277V single-phase commercial supply exceeds that range; for 277V applications you would need a different model rated for that input.

How does the LPV-100-24 compare to the LPV-150-24 when choosing between them?

Both are 24V IP67 constant-voltage drivers, but the LPV-100-24 delivers 100.8W / 4.2A on a 90–264 VAC input, whereas the LPV-150-24 delivers 151.2W / 6.3A on a narrower 180–305 VAC input. Use the LPV-100-24 when 120V mains compatibility or loads under 101W are the priority; use the LPV-150-24 when higher current capacity is needed and a 200V-class supply is available.

Model	Power	Voltage	Current	IP Rating
Mean Well S-LPV-100-24 Power Supply 100W 24V with AU/NZ plug	100.8W	24V	4.2A	IP67	View
Mean Well S-LPV-100-12 Power Supply 100W 12V with AU/NZ plug	102W	12V	8.5A	IP67	View
Mean Well LPV-100-48 LED Driver — 100.8W 48V 2.1A IP67 Waterproof	100.8W	48V	2.1A	IP67	View
Mean Well LPV-100-12 LED Driver — 102W 12V 8.5A IP67 Waterproof	102W	12V	8.5A	IP67	View
Mean Well LPV-100-36 LED Driver — 100.8W 36V 2.8A IP67 Waterproof	100.8W	36V	2.8A	IP67	View
Mean Well LPV-100-5 LED Driver — 60W 5V 12A IP67 Waterproof	60W	5V	12A	IP67	View
Mean Well LPV-100-15 LED Driver — 100.5W 15V 6.7A IP67 Waterproof	100.5W	15V	6.7A	IP67	View
