Mean Well MPS-45-13.5 Power Supply 45W 13.5V 3.3A

SKU MPS-45-13.5

Log in to see price Trade pricing & online ordering for account holders

End of Life, Succeeded by RPS-45-13.5

Available to order

Overview

MPS-45-13.5 is the 13.5V output model of this series: rated current 3.3A, rated power 44.55W, typical efficiency 76%.

Features

Universal AC input / Full range
Low leakage current <250μA
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Medical safety approved (2 x MOPP between primary to secondary)
100% full load burn-in test
Fixed switching frequency at 45KHz
3 years warranty

Specifications

MPS-45-13.5Specifications from the official datasheet (2021-09-15 edition)

OUTPUT

DC VOLTAGE: 13.5V
RATED CURRENT: 3.3A
CURRENT RANGE: 0 ~ 3.9A
RATED POWER: 44.55W
OUTPUT POWER (max.): 52W(+3.3V:35W)with 18CFM min. Forced air convection
RIPPLE & NOISE (max.)^Note.2: 100mVp-p
VOLTAGE ADJ. RANGE: 12.2 ~ 14.85V
VOLTAGE TOLERANCE^Note.3: ±2.0%
LINE REGULATION: ±1.0%
LOAD REGULATION: ±2.0%
SETUP, RISE TIME: 800ms, 30ms/230VAC 1200ms, 30ms/115VAC at full load
HOLD UP TIME (Typ.): 50ms/230VAC 16ms/115VAC at full load

INPUT

VOLTAGE RANGE: 90 ~ 264VAC 127 ~ 370VDC
FREQUENCY RANGE: 47 ~ 63Hz
EFFICIENCY(Typ.): 76%
AC CURRENT (Typ.): 1.2A/115VAC 0.7A/230VAC
INRUSH CURRENT (Typ.): COLD START 17A/115VAC 40A/230VAC
LEAKAGE CURRENT^Note.7: Earth leakage current < 250 μA/264VAC , Touch current < 60 μA/264VAC

PROTECTION

OVERLOAD: 53 ~ 75W (3.3V:36 ~ 55W) rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE: 15.5 ~ 18.2V Protection type : Hiccup mode, recovers automatically after fault condition is removed

ENVIRONMENT

WORKING TEMP.: -10 ~ +60℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY: -20 ~ +85℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.04%/℃ (0 ~ 50℃))
VIBRATION: 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC (Note 4)

SAFETY STANDARDS: ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1 approved
ISOLATION LEVEL: Primary-Secondary: 2xMOPP, Primary-Earth:1xMOPP
WITHSTAND VOLTAGE: I/P-O/P:4KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to EN55011 (CISPR11) Class B, EN61000-3-2,-3
EMC IMMUNITY: Compliance to EN61000-4-2,3,4,5,6,8,11, EN60601-1-2, medical level, criteria A

OTHERS

MTBF: 366.1Khrs min. MIL-HDBK-217F (25℃)
DIMENSION: 127*76*28mm (L*W*H)
PACKING: 0.18Kg; 72pcs/15.1Kg/1.28CUFT

Test conditions and notes7

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μf & 47μf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on a 360mm*360mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to "EMI testing of component power supplies." (as available on http://www.meanwell.com)
5. Mounting holes M1 and M2 should be grounded for EMI purposes.
6. Heat Sink HS1,HS2 can not be shorted.
7. Touch current was measured from primary input to DC output.

Technical drawings

MPS-45-13.5 Mechanical Specification — Mechanical Specification

MPS-45-13.5 Block Diagram — Block Diagram

MPS-45-13.5 Derating Curve — Derating Curve

Downloads

Catalogues1

Mean Well Catalog (Industrial) PDF Download

FAQ

Can I use the MPS-45-13.5 for a 13.5V communications or control device?

It is intended for loads that require a constant 13.5V output and stay within 44.55W and 3.3A. That makes it a fit for lower-power 13.5V equipment rather than systems that need a higher current margin.

Is this power supply suitable for 13.5V battery-backed control electronics or alarm-related hardware?

It can be used where the equipment specifically requires 13.5V constant voltage and the load remains at or below 3.3A and 44.55W. The answer depends on matching the device requirement to the published 13.5V output rather than using a nearby voltage model.

Can the MPS-45-13.5 power a compact embedded or industrial monitoring system?

Yes, for compact 13.5V monitoring or embedded loads within 44.55W, this model provides a constant-voltage output with a wide 90-264VAC input range. It is better suited to modest 13.5V loads than higher-power systems.

Is the MPS-45-13.5 meant for outdoor cabinets or exposed environments?

The listed operating temperature is -10°C to +60°C, but no IP rating is shown in the provided specs. Without an IP rating in the product data, outdoor exposure or wet-location suitability is not established here.

What are the main differences between the MPS-45-13.5 and other MPS family models?

This model is 44.55W at 13.5V and 3.3A. The other models on the MPS-45 sheet are MPS-45-3.3 26.4W 3.3V 8A, MPS-45-5 40W 5V 8A, MPS-45-7.5 40.5W 7.5V 5.4A, MPS-45-12 44.4W 12V 3.7A, MPS-45-15 45W 15V 3A, MPS-45-24 45.6W 24V 1.9A, MPS-45-27 45.9W 27V 1.7A, and MPS-45-48 48W 48V 1A. All share the 90-264VAC input, medical safety approvals and the 127*76*28mm size, so the main differences are output voltage, current and power.
