Mean Well NLDD-350H DC/DC LED Driver CC 350mA - Step-down

constant currentstep downhigh efficiency up to 97%IP67pin style

SKU:

NLDD-350H

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The NLDD is a Mean Well power converter (input range: 6~52VDC, operating temperature: -40~+85℃).

Key Features

✓ Input voltage range: 6~52VDC
✓ Wide operating temperature: -40~+85℃
✓ Protections: Short circuit / Over temperature
✓ Remote ON/OFF control
✓ Safety approvals: IEC61347 and EAC TP TC004
✓ 3 years warranty

Frequently Asked Questions

Can I use the NLDD-350H to drive a low-current LED downlight module?

Yes, if the LED downlight is designed for constant current operation at 350mA. This is a 60W step-down constant current driver, so it fits LED loads that need regulated current rather than a constant voltage supply.

Is the NLDD-350H suitable for signage modules or small LED arrays?

It can be a fit for signage modules or small LED arrays when the LEDs are intended to run from a 350mA constant current source. Because it is a step-down driver with a 6-52VAC input and 52-6V constant current range, the LED load has to stay within that operating window.

Can this driver be used in compact lighting assemblies where space is limited?

The NLDD-350H is very compact at 32.1 × 20.5 × 12.5 mm and weighs 0.0156 kg, which helps in small integrated lighting products. It is still a 60W constant current driver, so the electrical match matters as much as the physical size.

How do I know if my LED load is compatible with the NLDD-350H?

This model is for constant current LED loads, not constant voltage LED products. Its constant current output range is 52-6V, and the number of LEDs it can run depends on the forward voltage of each LED in the load rather than on a fixed LED count.

How does the NLDD-350H compare with other NLDD H-series drivers?

Within this 60W series, the listed siblings are NLDD-350HW at 0.35mA with 52-6V, NLDD-500H and NLDD-500HW at 0.5mA with 52-6V, NLDD-700H and NLDD-700HW at 0.7mA with 52-6V, NLDD-1050H and NLDD-1050HW at 1.05mA with 52-6V, and NLDD-1200H, NLDD-1200HW, NLDD-1400H, and NLDD-1400HW with 46-6V at 1.2mA or 1.4mA. The NLDD-350H is the pin-style 350mA option in that family.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well NLDD-1050HW DC/DC LED Driver CC 1050mA - Step-down Wire Type	60W	52V	1.05A	Indoor	View
Mean Well NLDD-700HW DC/DC LED Driver CC 700mA - Step-down Wire Type	60W	52V	0.7A	Indoor	View
Mean Well NLDD-700H DC/DC LED Driver CC 700mA - Step-down	60W	52V	0.7A	Indoor	View
Mean Well NLDD-500HW DC/DC LED Driver CC 500mA - Step-down Wire Type	60W	52V	0.5A	Indoor	View
Mean Well NLDD-500H DC/DC LED Driver CC 500mA - Step-down	60W	52V	0.5A	Indoor	View
Mean Well NLDD-350HW DC/DC LED Driver CC 350mA - Step-down Wire Type	60W	52V	0.35A	Indoor	View
Mean Well NLDD-1400HW DC/DC LED Driver CC 1400mA - Step-down Wire Type	60W	46V	1.4A	Indoor	View
Mean Well NLDD-1400H DC/DC LED Driver CC 1400mA - Step-down	60W	46V	1.4A	Indoor	View
Mean Well NLDD-1200HW DC/DC LED Driver CC 1200mA - Step-down Wire Type	60W	46V	1.2A	Indoor	View
Mean Well NLDD-1200H DC/DC LED Driver CC 1200mA - Step-down	60W	46V	1.2A	Indoor	View
Mean Well NLDD-1050H DC/DC LED Driver CC 1050mA - Step-down	60W	52V	1.05A	Indoor	View
