Mean Well NPF-90D-20 Power Supply 90W 20V - Dimmable
Please Login for Pricing
Description
Description
The NPF-90D is a 90W Mean Well DIN rail power converter with a 171mm profile (input range: 90~305VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 171mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.13-12, ENEC EN61347-1, EN61347-2-13, EN62384 independent, IP67
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesNPF Series
-
Power Rating90 Watt
-
Output Voltage20 Volt
-
Rated Current4.5 Ampere
-
Input Voltage90V~305V
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length17.1 cm
-
Width6.3 cm
-
Height3.75 cm
-
Weight0.77 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What dimming inputs does the NPF-90D-20 accept?
The NPF-90D-20 integrates 3-in-1 dimming, accepting PWM signal, 0–10V analog, and resistance control, all built in without external dimming accessories.
Is the NPF-90D-20 a good match for dimmable 20V LED panels in a medical imaging facility?
The NPF-90D-20 delivers 90W at 20V with a constant current of 4.5A and built-in dimming, making it suitable for medical imaging or examination room LED panels that require stable, adjustable illumination. Its UL and CE certifications support use in regulated medical facility environments.
How does the NPF-90D-20 differ from the NPF-60D-20?
Both are dimmable 20V IP67 drivers with 3-in-1 dimming, but differ in power: NPF-60D-20 is 60W at 3A (150.0 × 53.0 × 35.0 mm, 0.49 kg), while NPF-90D-20 is 90W at 4.5A (171.0 × 63.0 × 37.5 mm, 0.77 kg). Select based on the LED load’s total wattage.
Can the NPF-90D-20 operate in an outdoor carport or canopy structure exposed to rain?
Yes. The NPF-90D-20 is IP67-rated and operates from -40°C to +85°C, making it appropriate for outdoor carport or canopy LED lighting in wet conditions.
Does the NPF-90D-20 require a ground connection?
No. The NPF-90D-20 uses a Class II fully isolated plastic case without a functional ground (FG) terminal, so no protective earth wiring is required.
Other NPF-90D Models
8 other models| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Mean Well NPF-90D-54 Power Supply 90W 54V - Dimmable | 90.18W | 54V | 1.67A | IP67 | View |
| Mean Well NPF-90D-48 Power Supply 90W 48V - Dimmable | 90.24W | 48V | 1.88A | IP67 | View |
| Mean Well NPF-90D-42 Power Supply 90W 42V - Dimmable | 90.3W | 42V | 2.15A | IP67 | View |
| Mean Well NPF-90D-36 Power Supply 90W 36V - Dimmable | 90W | 36V | 2.5A | IP67 | View |
| Mean Well NPF-90D-30 Power Supply 90W 30V - Dimmable | 90W | 30V | 3A | IP67 | View |
| Mean Well NPF-90D-24 Power Supply 90W 24V - Dimmable | 90W | 24V | 3.75A | IP67 | View |
| Mean Well NPF-90D-15 Power Supply 90W 15V - Dimmable | 90W | 15V | 6A | IP67 | View |
| Mean Well NPF-90D-12 Power Supply 90W 12V - Dimmable | 90W | 12V | 7.5A | IP67 | View |
