Mean Well NPF-90D-24 Power Supply 90W 24V - Dimmable
Please Login for Pricing
Description
Description
The NPF-90D is a 90W Mean Well DIN rail power converter with a 171mm profile (input range: 90~305VAC, operating temperature: -40~+80℃).
Key Features
- ✓ 171mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+80℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.13-12, ENEC EN61347-1, EN61347-2-13, EN62384 independent, IP67
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesNPF Series
-
Power Rating90 Watt
-
Output Voltage24 Volt
-
Rated Current3.75 Ampere
-
Input Voltage90V~305V
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length17.1 cm
-
Width6.3 cm
-
Height3.75 cm
-
Weight0.77 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What dimming signals does the NPF-90D-24 support?
The NPF-90D-24 features built-in 3-in-1 dimming that accepts PWM signal, 0–10V analog, and resistance control simultaneously, enabling direct integration with most commercial lighting control platforms.
Can the NPF-90D-24 drive dimmable 24V LED high-bay fixtures in a large retail warehouse?
The NPF-90D-24 delivers 90W at 24V with a constant current of 3.75A and a CC range of 14–24V. Its built-in dimming makes it suitable for 24V LED high-bay fixtures where energy-saving dimming schedules are required, and its IP67 rating supports dusty warehouse environments.
What is the difference between the NPF-90D-24 and the NPF-90-24?
The NPF-90D-24 and NPF-90-24 share identical output (90W, 24V, 3.75A), IP67 rating, dimensions (171.0 × 63.0 × 37.5 mm), and weight (0.77 kg). The NPF-90D-24 adds built-in 3-in-1 dimming; the NPF-90-24 is fixed-output.
Is the NPF-90D-24 rated for outdoor installation in tropical climates with high humidity?
Yes. The NPF-90D-24 is IP67-rated for full dust and temporary water immersion protection, and its -40°C to +85°C operating range covers the high ambient temperatures common in tropical climates.
How many 24V, 30W LED modules can the NPF-90D-24 supply?
The NPF-90D-24 provides 90W total at 3.75A output current. It can supply three 30W modules (3 × 30W = 90W) as long as each module’s forward voltage is within the 14–24V CC range and the combined current does not exceed 3.75A.
Other NPF-90D Models
8 other models| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Mean Well NPF-90D-54 Power Supply 90W 54V - Dimmable | 90.18W | 54V | 1.67A | IP67 | View |
| Mean Well NPF-90D-48 Power Supply 90W 48V - Dimmable | 90.24W | 48V | 1.88A | IP67 | View |
| Mean Well NPF-90D-42 Power Supply 90W 42V - Dimmable | 90.3W | 42V | 2.15A | IP67 | View |
| Mean Well NPF-90D-36 Power Supply 90W 36V - Dimmable | 90W | 36V | 2.5A | IP67 | View |
| Mean Well NPF-90D-30 Power Supply 90W 30V - Dimmable | 90W | 30V | 3A | IP67 | View |
| Mean Well NPF-90D-20 Power Supply 90W 20V - Dimmable | 90W | 20V | 4.5A | IP67 | View |
| Mean Well NPF-90D-15 Power Supply 90W 15V - Dimmable | 90W | 15V | 6A | IP67 | View |
| Mean Well NPF-90D-12 Power Supply 90W 12V - Dimmable | 90W | 12V | 7.5A | IP67 | View |
