Mean Well PCD-25-1400A Power Supply 25W 1400mA
Please Login for Pricing
Description
Description
The PCD-25 is a 25W Mean Well power converter (input range: 40~58V).
Key Features
- ✓ Input voltage range: 40~58V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.0-08(except for PCD-25-350, PCD-25-700), ENEC EN613471, EN61347-2-13, EN62384(for B type only), IP42
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesPCD Series
-
Power Rating25.2 Watt
-
Output Voltage18 Volt
-
Rated Current1.4 Ampere
-
Input Voltage90V~135V
-
Standards MetBSI,CB,CE,EAC,ENEC,FCC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~60°C
-
Warranty3 Year
-
Length8.4 cm
-
Width5.7 cm
-
Height2.95 cm
-
Weight0.19 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the PCD-25-1400A for 1400mA LED downlights?
Yes, if the downlight is specified for constant current at 1400mA and the total LED forward-voltage load stays within 12-18V. The driver is rated for 25.2W, so the fixture load also needs to stay within that power limit.
Is the PCD-25-1400A suitable for signage modules that need higher current?
It can be suitable for signage modules when the module assembly requires 1400mA constant current and operates within the 12-18V constant-current range. Because this is a constant-current model, it is not the same thing as a constant-voltage LED power supply.
Can this driver run a compact small LED array?
Yes, if the small LED array is designed for 1400mA constant current and its total forward voltage falls between 12V and 18V. The exact number of LEDs depends on the forward voltage of each LED, not on a fixed LED count.
How do I check if my LEDs are compatible with the PCD-25-1400A?
Confirm that the LEDs need 1400mA constant current and that the total forward-voltage requirement stays inside the 12-18V constant-current range. The overall load also needs to remain within the 25.2W rating.
What kind of environment is this driver rated for?
The PCD-25-1400A uses an IP42 plastic casing and is rated for -30C to +60C operation. That points to protected indoor use rather than direct exposure to water or harsher outdoor conditions.
How is the PCD-25-1400A different from other 25W PCD drivers?
In the 25W class, the PCD-25-1400A/B use a 12-18V constant-current range, the PCD-25-1050A/B use 16-24V, and the PCD-25-700A/B use 24-36V, all at 25.2W. The PCD-25-350A/B shift to a 40-58V range at 20.3W, while larger 40W and 60W families expand both wattage and constant-current voltage range further.
Other PCD-25 Models
7 other models| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Mean Well PCD-25-1050B Power Supply 25W 1050mA | 25.2W | 24V | 1.05A | Indoor | View |
| Mean Well PCD-25-700B Power Supply 25W 700mA | 25.2W | 36V | 0.7A | Indoor | View |
| Mean Well PCD-25-700A Power Supply 25W 700mA | 25.2W | 36V | 0.7A | Indoor | View |
| Mean Well PCD-25-350B Power Supply 25W 350mA | 20.3W | 58V | 0.35A | Indoor | View |
| Mean Well PCD-25-350A Power Supply 16W 350mA | 20.3W | 58V | 0.35A | Indoor | View |
| Mean Well PCD-25-1400B Power Supply 25W 1400mA | 25.2W | 18V | 1.4A | Indoor | View |
| Mean Well PCD-25-1050A Power Supply 25W 1050mA | 25.2W | 24V | 1.05A | Indoor | View |
