Mean Well PCD-25-350A Power Supply 16W 350mA
Please Login for Pricing
Description
Description
The PCD-25 is a 25W Mean Well power converter (input range: 40~58V).
Key Features
- ✓ Input voltage range: 40~58V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.0-08(except for PCD-25-350, PCD-25-700), ENEC EN613471, EN61347-2-13, EN62384(for B type only), IP42
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesPCD Series
-
Power Rating20.3 Watt
-
Output Voltage58 Volt
-
Rated Current0.35 Ampere
-
Input Voltage90V~135V
-
Standards MetBSI,CB,CE,EAC,ENEC,FCC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~60°C
-
Warranty3 Year
-
Length8.4 cm
-
Width5.7 cm
-
Height2.95 cm
-
Weight0.19 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the PCD-25-350A for a small LED array?
Yes, if the array is designed for constant current operation at 350mA and its total forward voltage falls within 40-58V. This driver supports up to 20.3W, so the array also needs to stay within that power level.
Is the PCD-25-350A a good fit for LED signage modules?
It can be a fit for signage modules that are specified for a 350mA constant current driver and operate within the 40-58V constant current range. It should not be used in place of a constant voltage supply for modules built around fixed voltage input.
Can this model be used with LED downlights that need lower drive current?
Yes, for downlights that are built for 350mA constant current input and fall inside the 40-58V output window. The match depends on the fixture's required current and forward voltage, not just on wattage alone.
How should I size the LED load for the PCD-25-350A?
Match it to a constant current LED load rated at 350mA with a combined forward voltage of 40-58V. The number of LEDs depends on each LED's forward voltage, so compatibility is based on total voltage and current rather than a stated LED quantity.
Is the PCD-25-350A intended for exposed locations or temperature-sensitive areas?
This model has an IP42 plastic casing and an operating temperature range of -30°C to +60°C. It is a better fit for applications where those enclosure and temperature limits match the project requirements.
Other PCD-25 Models
7 other models| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Mean Well PCD-25-1050B Power Supply 25W 1050mA | 25.2W | 24V | 1.05A | Indoor | View |
| Mean Well PCD-25-700B Power Supply 25W 700mA | 25.2W | 36V | 0.7A | Indoor | View |
| Mean Well PCD-25-700A Power Supply 25W 700mA | 25.2W | 36V | 0.7A | Indoor | View |
| Mean Well PCD-25-350B Power Supply 25W 350mA | 20.3W | 58V | 0.35A | Indoor | View |
| Mean Well PCD-25-1400B Power Supply 25W 1400mA | 25.2W | 18V | 1.4A | Indoor | View |
| Mean Well PCD-25-1400A Power Supply 25W 1400mA | 25.2W | 18V | 1.4A | Indoor | View |
| Mean Well PCD-25-1050A Power Supply 25W 1050mA | 25.2W | 24V | 1.05A | Indoor | View |
