Mean Well PD-65A Power Supply 65W 5V 12V

Q: Can I use the PD-65A for a 5V controller board with 12V auxiliary loads in an industrial cabinet?

Yes, this model is suited to constant-voltage systems that use the 5V and 12V outputs indicated by the model name. It provides 61.1W total power, a 5V output rated at 5.5A, and accepts 90-264VAC input, which fits small industrial control or embedded assemblies that need those rails.

Q: Is the PD-65A a good fit for embedded test fixtures or automation jigs that need stable 5V power?

It can be a fit where the main requirement is regulated 5V power for embedded electronics, with 61.1W total available and 5.5A on the 5V output. Because it is a constant-voltage supply with 90-264VAC input, it suits bench or factory test equipment designed around those limits.

Q: Can I use the PD-65A in a small PLC or relay control panel that mixes low-voltage logic and support circuits?

Yes, for compact control panels that need a constant-voltage supply and stay within 61.1W total load. The 5V output is rated at 5.5A, and the model name identifies a 12V rail as well, so it is better aligned to mixed-voltage control hardware than a single-output-only unit.

Q: Is the PD-65A suitable for outdoor or harsh-environment use?

The supplied specs do not list an IP rating, so outdoor exposure is not established from this data. Its operating temperature range is -10°C to +60°C, so it is better suited to protected indoor equipment or an enclosure that keeps the unit within that range.

Q: How does the PD-65A compare with other PD series models?

Within the listed PD family, lower-power options are PD-2503 at 24.9W, PD-2505 at 25W 5V 2.5A, PD-2512 at 24W 12V 1A, PD-2515 at 24W 15V 0.8A, PD-25A at 24.9W 5V 2.1A, PD-25B at 25.2W 5V 1.2A, PD-45A at 40W 5V 3.2A, and PD-45B at 44.8W 5V 3.2A. Nearby higher-output options are PD-65B at 65.5W 5V 3.5A, plus PD-110A and PD-110B at 103W.

low leakage current < 0.5mA, low cost, high reliability

SKU:

PD-65A

Please for Pricing

Notify me when it's back in stock

Description

<0.75mA/240VAC

Key Features

✓Universal AC input / Full range
✓Low leakage current < 0.5mA
✓Protections: Short circuit / Overload / Over voltage / Over temperature
✓Cooling by free air convection
✓100% full load burn-in test
✓Fixed switching frequency at 65KHz
✓Low cost
✓High reliability
✓2 years warranty

Specifications

Brand

Mean Well
Series

PD Series
Power Rating

61.1 Watt
Output Voltage

5 Volt
Rated Current

5.5 Ampere
Input Voltage

90V~264V
Standards Met

CB,CE,TUV,UL
Operation Mode

Constant Voltage
Operating Temperature

-10°C~60°C
Warranty

2 Year
Length

12.7 cm
Width

7.6 cm
Height

4.2 cm
Weight

0.24 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the PD-65A for a 5V controller board with 12V auxiliary loads in an industrial cabinet?

Yes, this model is suited to constant-voltage systems that use the 5V and 12V outputs indicated by the model name. It provides 61.1W total power, a 5V output rated at 5.5A, and accepts 90-264VAC input, which fits small industrial control or embedded assemblies that need those rails.

Is the PD-65A a good fit for embedded test fixtures or automation jigs that need stable 5V power?

It can be a fit where the main requirement is regulated 5V power for embedded electronics, with 61.1W total available and 5.5A on the 5V output. Because it is a constant-voltage supply with 90-264VAC input, it suits bench or factory test equipment designed around those limits.

Can I use the PD-65A in a small PLC or relay control panel that mixes low-voltage logic and support circuits?

Yes, for compact control panels that need a constant-voltage supply and stay within 61.1W total load. The 5V output is rated at 5.5A, and the model name identifies a 12V rail as well, so it is better aligned to mixed-voltage control hardware than a single-output-only unit.

Is the PD-65A suitable for outdoor or harsh-environment use?

The supplied specs do not list an IP rating, so outdoor exposure is not established from this data. Its operating temperature range is -10°C to +60°C, so it is better suited to protected indoor equipment or an enclosure that keeps the unit within that range.

How does the PD-65A compare with other PD series models?

Within the listed PD family, lower-power options are PD-2503 at 24.9W, PD-2505 at 25W 5V 2.5A, PD-2512 at 24W 12V 1A, PD-2515 at 24W 15V 0.8A, PD-25A at 24.9W 5V 2.1A, PD-25B at 25.2W 5V 1.2A, PD-45A at 40W 5V 3.2A, and PD-45B at 44.8W 5V 3.2A. Nearby higher-output options are PD-65B at 65.5W 5V 3.5A, plus PD-110A and PD-110B at 103W.

Model	Power	Voltage	Current
Mean Well PD-65B Power Supply 65W 5V 24V	65.5W	5V	3.5A	View
Mean Well PD-45B Power Supply 45W 5V 24V	44.8W	5V	3.2A	View
Mean Well PD-45A Power Supply 45W 5V 12V	40W	5V	3.2A	View
Mean Well PD-25B Power Supply 25W 5V 24V	25.2W	5V	1.2A	View
Mean Well PD-25A Power Supply 25W 5V 12V	24.9W	5V	2.1A	View
Mean Well PD-2512 Power Supply 25W 15V -15V	24W	15V	0.8A	View
Mean Well PD-2512 Power Supply 25W 12V -12V	24W	12V	1A	View
Mean Well PD-2505 Power Supply 25W 5V -5V	25W	5V	2.5A	View
