Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well ELG-200-24A-3Y AC-DC Single output LED Driver Mix Mode (CV+CC) with PFC

metal case, IP65/IP67, 5 years warranty

SKU:

ELG-200-24A-3Y

Please for Pricing

Notify me when it's back in stock

Description

The ELG-200-24A is a 200W Mean Well power converter (input range: 100~305VAC).

Key Features

✓ Input voltage range: 100~305VAC
✓ DC output voltage adjustable ±10%
✓ 3.75KVAC reinforced I/O isolation
✓ Cooling by free air convection
✓ Protections: Short circuit / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: UL8750(type”HL”), CSA C22.2 No. 250.13-12; EAC TP TC 004;BISIS15885(for 12/12A/12B/12DA/24/24A/24B/24DA/36/36A/36B/42A/42B/48/48A/48B/54A/54B only); GB19510.14,GB19510.1; IP65 or IP67;KC61347-1,KC61347-2-13
✓ 3 years warranty

Specifications

Brand

Mean Well
Series

ELG Series
Power Rating

200 Watt
Output Voltage

24 Volt
Rated Current

8.4 Ampere
Input Voltage

100V~305V
Standards Met

BSMI,CB,CE,EAC,UL
Operation Mode

Constant Current,Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

5 Year
Length

24.4 cm
Width

7.1 cm
Height

3.75 cm
Weight

1.22 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can the ELG-200-24A-3Y be used for 24V LED strip lighting in commercial signage?

Yes. The ELG-200-24A-3Y provides 200W at 24V with an 8.4A output, giving it sufficient capacity for large illuminated signs, architectural LED strips, and display lighting running at 24V.

How much 24V LED strip can the ELG-200-24A-3Y support?

With 200W available at 24V, divide by your strip's rated wattage per meter — a 14.4 W/m strip allows approximately 13.9 meters and a 9.6 W/m strip allows roughly 20.8 meters. Confirm the rated power per meter on your specific strip before sizing the installation.

Is the ELG-200-24A-3Y rated for outdoor or wet-location use?

The ELG-200-24A-3Y has an IP65 rating, providing full dust protection and resistance to low-pressure water jets. It is suitable for covered outdoor enclosures, outdoor signage cabinets, and similar applications where direct rain submersion is not expected.

What certifications does the ELG-200-24A-3Y carry, and which markets does it cover?

The ELG-200-24A-3Y holds BSMI, CB, CE, EAC, and UL certifications, covering Taiwan (BSMI), international safety standards (CB), Europe (CE), the Eurasian Economic Union (EAC), and North America (UL).

Can the ELG-200-24A-3Y be used for landscape or pathway LED lighting that operates year-round outdoors?

Its IP65 rating and -40°C to +90°C operating temperature range make it viable for year-round covered outdoor installations such as landscape pathway lighting or facade uplighting, provided the unit is housed in an enclosure that shields it from direct rain and submersion.

Is the ELG-200-24A-3Y suitable for powering 24V LED modules in an outdoor illuminated cabinet sign?

Yes. The 200W output at 24V handles the demands of multi-module LED sign cabinets, and the IP65 construction allows mounting inside an outdoor sign enclosure where condensation and humidity may be present. Ensure cabinet venting keeps ambient temperature within the -40°C to +90°C operating range.

Model	Power	Voltage	Current	IP Rating
Mean Well S-ELG-200-24 Power Supply 200W 24V with AU/NZ plug	201.6W	24V	8.4A	IP67	View
Mean Well S-ELG-200-12 Power Supply 192W 12V with AU/NZ plug	192W	12V	16A	IP67	View
Mean Well ELG-200-24-3Y AC-DC Single output LED Driver Mix Mode (CV+CC) with PFC	200W	24V	8.4A	IP67	View
Mean Well ELG-200-12-3Y AC-DC Single output LED Driver Mix Mode (CV+CC) with PFC	200W	12V	16A	IP67	View
Mean Well ELG-200-48A-3Y AC-DC Single output LED Driver Mix Mode CV+CC 200W	200W	48V	4.16A	IP65	View
Mean Well ELG-200-48-3Y AC-DC Single output LED Driver Mix Mode (CV+CC) with PFC	200W	48V	4.16A	IP67	View
Mean Well ELG-200-24B Power Supply 200W 24V - Dimmable	201.6W	24V	8.4A	IP67	View
Mean Well ELG-200-12A Power Supply 192W 12V 3-wire Input - Adjustable	192W	12V	16A	IP65	View
Mean Well S-ELG-200-24A Power Supply 200W 24V - Adjustable with AU/NZ plug	201.6W	24V	8.4A	IP65	View
