Mean Well GSM60B48-P1J Power Supply 60W 48V
Please Login for Pricing
Description
Description
The GSM60B48 is a 60W Mean Well power converter (input range: 80~264VAC, operating temperature: -30~+70℃).
Key Features
- ✓ Input voltage range: 80~264VAC
- ✓ 4KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Safety approvals: ISOLATION LEVEL
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesGSM Series
-
Power Rating60 Watt
-
Output Voltage48 Volt
-
Rated Current1.25 Ampere
-
Input Voltage80V~264V
-
Standards MetCB,CE,EAC,FCC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length12.5 cm
-
Width5 cm
-
Height3.15 cm
-
Weight0.32 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the GSM60B48-P1J to power 48V industrial networking or telecom equipment?
Yes, for equipment that is designed for 48V DC constant-voltage input. This model supplies up to 1.25A with a maximum output of 60W, so the load needs to remain within those limits.
Is this 48V power supply suitable for embedded communications devices or control interfaces?
It can be suitable for 48V embedded or communications hardware that requires a fixed-voltage DC source. The important electrical limits are 48V output, 1.25A maximum current, and 60W total power.
Will the GSM60B48-P1J work for 48V industrial monitoring or data collection systems?
It can be used where the end device expects 48V DC and the total draw stays at or below 1.25A. Because it is a constant-voltage supply, it should be paired only with loads specified for 48V input.
Can this model be used on a bench or in a control panel where AC input may vary?
Yes, the 80-264VAC input range supports use across a broad AC input range. On the DC side, it remains a 48V constant-voltage source with a 60W maximum output.
Is the GSM60B48-P1J suitable for outdoor environments or temperature extremes?
The specified operating range is -30°C to +70°C, so the temperature rating is suitable for a wide range of environments. No IP rating is listed, so outdoor or wet-location suitability cannot be verified from the provided specifications.
