Mean Well NPB-240-24TB Battery Charger 240W 24V Terminal Block 8A

wide voltage rangemetal enclosure for better heat dissipationeasy and flexible adjustment for voltage and current2 or 3 stage selectable by dip switch

SKU:

NPB-240-24TB

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The NPB-240 is a 240W Mean Well DIN rail power converter with a 182.7mm profile (input range: 90~264VAC).

Key Features

✓ 182.7mm width — DIN rail TS-35 compatible
✓ Input voltage range: 90~264VAC
✓ 3KVAC reinforced I/O isolation
✓ Cooling by free air convection
✓ Protections: Short circuit / Over voltage / Over temperature / Reverse polarity
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: CB IEC62368-1,IEC60335-1/2-29, Dekra BS EN/EN62368-1,BS EN/EN60335-1/2-29, UL62368-1, AS/NZS60335-1/2-29, EAC TP TC 004
✓ 3 years warranty

Frequently Asked Questions

What is the Mean Well NPB-240-24TB used for?

The NPB-240-24TB is an AC-DC battery charger and power supply designed for 24V-class applications. This model provides up to 240W of output and is suited to commercial or industrial environments where a regulated 28.8Vdc output at up to 8A is required.

What are the main output specifications of the NPB-240-24TB?

This model is rated for 240W output power with a nominal output of 28.8Vdc. Its rated output current is 8A, making it appropriate for applications that need a higher-power 24V battery charging solution.

Does the NPB-240-24TB support multi-stage battery charging?

Yes. The product description specifies 2-stage or 3-stage charging capability, which is useful for buyers comparing chargers based on charging profile support. That makes this model more application-specific than a basic fixed-output power supply.

Can this charger operate in demanding temperature conditions?

The NPB-240-24TB has a specified operating temperature range from -30°C to 70°C. That wide range makes it a practical option for industrial environments where ambient conditions can vary significantly.

What kind of AC input does the NPB-240-24TB accept?

This model is specified with universal AC input. For B2B buyers, that means it is intended for use across a wide range of standard AC supply environments without requiring a region-specific input version.

How heavy is the Mean Well NPB-240-24TB, and what warranty does it include?

The unit weight is 1.3 kg. Mean Well specifies this model with a 3-year warranty, which is relevant for buyers evaluating lifecycle cost and long-term equipment support.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Battery Type	Battery Voltage	Charging Current
Mean Well NPB-240-48XLR Battery Charger 240W 48V 3 Pin Power Pin 4A	240W	Lithium and Lead Acid Battery	57.6V	—	View
Mean Well NPB-240-48TB Battery Charger 240W 48V Terminal Block 4A	240W	Lithium and Lead Acid Battery	57.6V	—	View
Mean Well NPB-240-48AD1 Battery Charger 240W 48V Anderson Connector 4A	240W	Lithium and Lead Acid Battery	57.6V	—	View
Mean Well NPB-240-24XLR Battery Charger 240W 24V 3 Pin Power Pin 8A	240W	Lithium and Lead Acid Battery	28.8V	—	View
Mean Well NPB-240-24AD1 Battery Charger 240W 24V Anderson Connector 8A	240W	Lithium and Lead Acid Battery	28.8V	—	View
Mean Well NPB-240-12XLR Battery Charger 240W 12V 3 Pin Power Pin 13.5A	240W	Lithium and Lead Acid Battery	14.4V	—	View
Mean Well NPB-240-12TB Battery Charger 240W 12V Terminal Block 13.5A	240W	Lithium and Lead Acid Battery	14.4V	—	View
Mean Well NPB-240-12AD1 Battery Charger 240W 12V Anderson Connector 13.5A	240W	Lithium and Lead Acid Battery	14.4V	—	View
