Mean Well ELG-200-12AB Power Supply 192W 12V - Adjustable and Dimma...
Log in to see priceThe ELG-200 is a 200W Mean Well power converter (input range: 100~305VAC).
Key Features
- ✓ Input voltage range: 100~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”), CSA C22.2 No. 250.13-12;IEC/EN/AS/NZS 61347-1, IEC/EN/AS/NZS 61347-2-13 UL8750 EAC TP TC 004;BIS IS15885(for 12/12B/24/24B/36/36A/42A/48/48A/54A only) GB19510.14,GB19510.1; IP65 or IP67; KC61347 1 KC61347 2 13
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesELG Series
-
Power Rating192 Watt
-
Output Voltage12 Volt
-
Rated Current16 Ampere
-
Input Voltage100V~305V
-
Standards MetBSI,CB,CCC,CE,EAC,ENEC,KC,RCM,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty5 Year
-
Length24.4 cm
-
Width7.1 cm
-
Height3.75 cm
-
Weight1.22 kg
::specification::
Frequently Asked Questions
What dimming interfaces does the ELG-200-12AB support?
The ELG-200-12AB combines output adjustability via potentiometer (the 'A' feature) with a built-in 3-in-1 dimming interface supporting 0–10V analog, PWM, and resistance dimming signals (the 'B' feature). This allows it to interface with most commercial lighting-control and building-management systems.
Can the ELG-200-12AB be used in 12V LED installations that require dimmable control?
Yes. The ELG-200-12AB is purpose-built for applications where both output trimming and dynamic dimming are needed, such as dimmable 12V LED strip systems in hospitality, retail, or architectural lighting. Its 192W / 12V / 16A rating supports substantial LED loads.
Is the ELG-200-12AB suitable for outdoor LED signage applications?
The ELG-200-12AB carries an IP65 water-resistance rating, making it suitable for sheltered outdoor cabinets and covered LED signage enclosures where rain splash is a concern. It should not be directly submerged or exposed to high-pressure water.
How many meters of 12V LED strip can the ELG-200-12AB drive?
The ELG-200-12AB provides 192W at 12V and 16A. For a 14.4W/m strip, that allows approximately 13 meters; for a 9.6W/m strip, approximately 20 meters. Always check your strip's rated power per meter and leave a 20% headroom margin for long-term reliability.
Can the ELG-200-12AB operate in cold outdoor environments?
Yes. The ELG-200-12AB is rated for -40°C to +90°C operation, covering sub-zero winter conditions without derating. Its IP65 rating additionally protects against condensation and moisture ingress in variable-temperature outdoor environments.
Is the ELG-200-12AB appropriate for 12V LED lighting in a museum or gallery with dimming control?
Yes. The ELG-200-12AB's 0–10V, PWM, and resistance dimming inputs make it compatible with the lighting-control systems commonly used in museums and galleries. The adjustable output allows precise current matching to sensitive LED fixtures, and the 192W capacity suits multi-fixture circuits.
