Over 15 years experience of providing support of MEAN WELL Power Supplies
Description
Description
Features
100~305VAC wide input range |
Built-in active PFC |
Protections: Short circuit / Over voltage/Over temperature |
No load power consumption <0.5W |
High efficiency up to 93% |
Suitable for LED lighting and street lighting applications |
Cooling by free air convection |
100% full load burn-in test |
5 years warranty |
General Specification
AC input voltage range | 100~305VAC;142~431VDC |
AC inrush current | Cold start, 65 at 230VAC |
DC adjustment range | ±10% rated output voltage |
Over voltage protection | 110%~140% rated output voltage |
Setup, rise, hold up time | 500ms |
Withstand voltage | I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 1.5kVAC |
Working temperature | -40~+80°C (refer to output derating curve) |
Safety standards | UL8750 approved |
EMC standards | EN55015, EN61000-3-2 class C,EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, GB17743,GB17625.1 |
Dimension (LxWxH) | 244x71x37.5 |
Packing | 12pcs / 15.2kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesELG Series
-
Power Rating200 Watt
-
Output Voltage114 Volt
-
Rated Current1.75 Ampere
-
Input Voltage100V~305V
-
Standards MetBSMI,CB,CE,EAC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length24.4 cm
-
Width7.1 cm
-
Height3.75 cm
-
Weight1.22 kg
