Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well HDR-100-15N Ultra Slim Step Shape Power Supply 100W 15V - DIN Rail

step size, isolation class II, DC output adjustable, no load power consumption
SKU:
HDR-100-15N
Please for Pricing
|

Description

Features

Universal AC input / Full range
Installed on DIN rail TS35 / 7.5 or 15
Protections: Short circuit / Overload / Over voltage
No load power consumption <0.3W
Ultra slim design with 70mm(4SU) width
Isolation class II
Cooling by free air convection
LED indicator for power on
3 years warranty

General Specification

AC input voltage range 85~264VAC; 120~370VDC
AC inrush current Cold start 35A at 115VAC, 70A at 230VAC
DC adjustment range ±10% rated output voltage
Overload protection 110%~145% constant current limiting, auto-recovery
Over voltage protection 115%~135% rated output voltage
Setup, rise, hold up time 500ms, 60ms, 30ms
Withstand voltage I/P-O/P:4kVAC
Working temperature -30~+70°C (refer to output derating curve)
Vibration 10~500Hz, 2G 10min./1cycle, period for 60min. Each along X, Y, Z axes
Safety standards UL508, UL,IEC 62368-1, EN61588-1,2-16
EMC standards EN55032 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
Connection I/P: 2 poles, O/P: 4 poles screw DIN terminal
Dimension (LxWxH) 70x90x54.5
Packing 48pcs / 14kg

Specifications
  • Brand
    Mean Well
  • Series
    HDR Series
  • Power Rating
    97.5 Watt
  • Output Voltage
    15 Volt
  • Rated Current
    6.5 Ampere
  • Input Voltage
    85V~264V
  • Standards Met
    BSMI,CB,CE,cUL,EAC,RCM,TUV,UL
  • Operating Temperature
    -30°C~70°C
  • Warranty
    3 Year
  • Length
    9 cm
  • Width
    7 cm
  • Height
    5.45 cm
  • Weight
    0.27 kg

File Downloads

::specification::

Payment & Security

Payment methods

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

What control panel loads is the HDR-100-15N sized for?

At 97.5W and 6.5A on a 15V bus, the HDR-100-15N suits applications such as industrial relay modules, field bus power supplies, and 15V sensor networks in control panels. Its DIN rail-mount step-shape body makes it easy to slot into standard enclosures alongside other rail components.

How does the HDR-100-15N differ from the HDR-100-15?

The HDR-100-15N is rated at 97.5W / 6.5A compared to the HDR-100-15 at 92W / 6.13A. Both are physically identical at 90.0 × 70.0 × 54.5 mm, weigh 0.27 kg, carry the same full certification set, and come with a 3-year warranty.

Does the HDR-100-15N support universal input voltage?

Yes, the HDR-100-15N accepts 85–264VAC input, covering the full range of worldwide mains voltages. No voltage selector switch is required when deploying across different regions.

Is the output voltage field-adjustable on the HDR-100-15N?

Yes, the DC output voltage on the HDR-100-15N is adjustable. The no-load power consumption remains below 0.3W, which is useful in continuously energized panels where standby efficiency matters.
