Mean Well HDR-100-24N Ultra Slim Step Shape Power Supply 100W 24V -...
Please Login for Pricing
Description
Description
The HDR-100 is a 100W Mean Well power converter (input range: 85~2 VAC).
Key Features
- ✓ Input voltage range: 85~2 VAC
- ✓ DC output voltage adjustable ±10%
- ✓ Cooling by free air convection
- ✓ Protections: Overload / Over voltage
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesHDR Series
-
Power Rating100.8 Watt
-
Output Voltage24 Volt
-
Rated Current4.2 Ampere
-
Input Voltage85V~264V
-
Standards MetBSMI,CB,CE,cUL,EAC,RCM,TUV,UL
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length9 cm
-
Width7 cm
-
Height5.45 cm
-
Weight0.27 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What 24V applications is the HDR-100-24N sized for?
At 100.8W and 4.2A on a 24VDC bus, the HDR-100-24N can power PLC backplanes, distributed I/O racks, field devices, and small HVAC/BMS controllers mounted in DIN rail enclosures. The slim step-shape profile keeps panel layouts compact.
How does the HDR-100-24N differ from the standard HDR-100-24?
The HDR-100-24N is rated 100.8W / 4.2A versus the HDR-100-24 at 92W / 3.83A. Both use the same 90.0 × 70.0 × 54.5 mm housing and carry the same certifications (BSMI, CB, CE, cUL, EAC, c-RCM, TÜV, UL) with a 3-year warranty.
Does the HDR-100-24N accept both 120V and 240V mains?
Yes, its 85–264VAC universal input accommodates both North American 120V and European/international 240V mains without requiring input voltage selection. This makes it suitable for global panel builds.
What are the enclosure requirements for the HDR-100-24N?
The HDR-100-24N is designed for installation inside a control cabinet or enclosure and does not carry an IP rating on its own. Operating temperature is -30°C to +70°C, which suits most indoor and protected outdoor enclosure deployments.
Other HDR-100 Models
7 other models| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Mean Well HDR-100-24 Ultra Slim Step Shape Power Supply 100W 24V - DIN Rail | 92W | 24V | 3.83A | Indoor | View |
| Mean Well HDR-100-12 Ultra Slim Step Shape Power Supply 100W 12V - DIN Rail | 82.5W | 12V | 7.1A | Indoor | View |
| Mean Well HDR-100-48N Ultra Slim Step Shape Power Supply 100W 48V - DIN Rail | 100.8W | 48V | 2.1A | Indoor | View |
| Mean Well HDR-100-48 Ultra Slim Step Shape Power Supply 100W 48V - DIN Rail | 92.2W | 48V | 1.92A | Indoor | View |
| Mean Well HDR-100-15N Ultra Slim Step Shape Power Supply 100W 15V - DIN Rail | 97.5W | 15V | 6.5A | Indoor | View |
| Mean Well HDR-100-15 Ultra Slim Step Shape Power Supply 100W 15V - DIN Rail | 92W | 15V | 6.13A | Indoor | View |
| Mean Well HDR-100-12N Ultra Slim Step Shape Power Supply 100W 12V - DIN Rail | 90W | 12V | 7.5A | Indoor | View |
