Description
Description
Features
Universal AC input/full rauge |
Fully encapsulated with IP67 level |
Protections: Short circuit / Over voltage |
Constant current design |
Withstand 300VAC surge input for 5 seconds |
High efficiency up to 90% |
Class II power unit, no F.G. |
Cooling by free air convection |
100% full load burn-in test |
Low cost, high reliability |
Suitable for LED lighting and moving sign applications |
2 years warranty |
General Specification
AC input voltage range | 180~305VAC |
AC inrush current | Cold start, 40A at 230VAC |
Over voltage protection | 105%~135% rated output voltage |
Withstand voltage | I/P-O/P: 3kVAC |
Working temperature | -25~+50°C |
Vibration | 10~500Hz, 2G 10 minutes /1 cycle, period for 60 minutes each along X, Y, Z axes |
Safety standards | IP67 approved;Design refer to TUV EN60950-1 |
EMC standards | EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11,EN55024 |
Connection Input | UL rated, SJTW 18AWGx2C (30cm) |
Connection Output | UL rated, SJTW 18AWGx2C (30cm) |
Dimension (LxWxH)(mm) | 191x 63x 37.5 |
Specifications
Specifications
-
BrandMean Well
-
SeriesLPC Series
-
Power Rating151.2 Watt
-
Output Voltage108 Volt
-
Rated Current1.4 Ampere
-
Input Voltage180V~305V
-
Standards MetCE,EAC
-
Operation ModeConstant Current
-
Operating Temperature-25°C~50°C
-
Warranty2 Year
-
Length19.1 cm
-
Width6.3 cm
-
Height3.75 cm
-
Weight0.74 kg
