Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well MDS15A-05 DC-DC Converter - 15W - 9~18V in 5V out

Q: Can I use the MDS15A-05 to power a 5V industrial controller or embedded computer?

Yes, this model provides constant 5V output at up to 3A, with 15W total output power. That makes it suitable for higher-current 5V controller boards, embedded computers, and processing modules that fit within that output limit.

Q: Is the MDS15A-05 a good fit for 5V automation peripherals and communication hardware?

It can support 5V automation peripherals, communication devices, and interface electronics that need more current headroom than a 6W converter provides. With 3A available at 5V, it suits low-voltage equipment that has a heavier 5V load profile.

Q: Can this 15W converter run multiple low-power 5V electronics in one system?

It is better suited to grouped low-power 5V electronics than a smaller 6W unit because it offers 15W total and up to 3A output current. As long as the combined load stays within 5V, 3A, and 15W, it can serve that role.

Q: Is the MDS15A-05 suitable for outdoor applications or unsealed enclosures?

The operating temperature range is -40C to +90C, so the thermal specification is broad. However, no IP rating is listed in the provided data, so these specs do not confirm protection for exposed outdoor or wet environments.

Q: How does the MDS15A-05 compare with the other MDS15A models?

The listed MDS15A siblings are all 15W converters. Their outputs are MDS15A-05 at 5V and 3A, MDS15A-12 at 12V and 1.25A, MDS15A-15 at 15V and 1A, and MDS15A-24 at 24V and 625A.

SKU:

MDS15A-05

Please for Pricing

Notify me when it's back in stock

Description

Features

DIP 2"x1" package with international standard pinout

2:1 wide input range

Low patient leakage current <5µA

Wide operating temperature range -40~+90℃

Medical safety approved(2xMOPP) according to IEC60601-1

Protections: Short circuit(Continuous)/Overload/Input under voltage

4000VAC high I/O isolation(Reinforced isolation)

3 years warranty

General Specification

Voltage accuracy	±1%
Efficiency	88%
Short circuit protection	Continuous, automatic recovery
Working temperature	-40°C to +90°C
Temp. Coefficient	0.03% / ℃ (0 ~ 70℃)
Dimension (LxWxH) (mm)	50.825.412mm (210.47 inch)

Specifications

Brand

Mean Well
Series

MDS Series
Power Rating

15 Watt
Output Voltage

5 Volt
Rated Current

3 Ampere
Input Voltage

9V~18V
Standards Met

CE,EAC,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

5.08 cm
Width

2.54 cm
Height

1.2 cm
Weight

0.03 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the MDS15A-05 to power a 5V industrial controller or embedded computer?

Yes, this model provides constant 5V output at up to 3A, with 15W total output power. That makes it suitable for higher-current 5V controller boards, embedded computers, and processing modules that fit within that output limit.

Is the MDS15A-05 a good fit for 5V automation peripherals and communication hardware?

It can support 5V automation peripherals, communication devices, and interface electronics that need more current headroom than a 6W converter provides. With 3A available at 5V, it suits low-voltage equipment that has a heavier 5V load profile.

Can this 15W converter run multiple low-power 5V electronics in one system?

It is better suited to grouped low-power 5V electronics than a smaller 6W unit because it offers 15W total and up to 3A output current. As long as the combined load stays within 5V, 3A, and 15W, it can serve that role.

Is the MDS15A-05 suitable for outdoor applications or unsealed enclosures?

The operating temperature range is -40C to +90C, so the thermal specification is broad. However, no IP rating is listed in the provided data, so these specs do not confirm protection for exposed outdoor or wet environments.

How does the MDS15A-05 compare with the other MDS15A models?

The listed MDS15A siblings are all 15W converters. Their outputs are MDS15A-05 at 5V and 3A, MDS15A-12 at 12V and 1.25A, MDS15A-15 at 15V and 1A, and MDS15A-24 at 24V and 625A.

Model	Power	Voltage	Current	IP Rating
Mean Well MDS15C-24 DC-DC Converter - 15W - 36~75V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15C-15 DC-DC Converter - 15W - 36~75V in 15V out	15W	15V	1A	Indoor	View
Mean Well MDS15C-12 DC-DC Converter - 15W - 36~75V in 12V out	15W	12V	1.25A	Indoor	View
Mean Well MDS15C-05 DC-DC Converter - 15W - 36~75V in 5V out	15W	5V	3A	Indoor	View
Mean Well MDS15B-24 DC-DC Converter - 15W - 18~36V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15B-15 DC-DC Converter - 15W - 18~36V in 15V out	15W	15V	1A	Indoor	View
Mean Well MDS15B-12 DC-DC Converter - 15W - 18~36V in 12V out	15W	12V	1.25A	Indoor	View
Mean Well MDS15B-05 DC-DC Converter - 15W - 18~36V in 5V out	15W	5V	3A	Indoor	View
Mean Well MDS15A-24 DC-DC Converter - 15W - 9~18V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15A-15 DC-DC Converter - 15W - 9~18V in 15V out	15W	15V	1A	Indoor	View
Mean Well MDS15A-12 DC-DC Converter - 15W - 9~18V in 12V out	15W	12V	1.25A	Indoor	View
