Mean Well MDS15A-15 DC-DC Converter - 15W - 9~18V in 15V out

Q: Can I use the MDS15A-15 for 15V industrial instrumentation or analog control circuits?

Yes, it is designed as a constant-voltage 15V output unit rated for 15W and 1A. That makes it suitable for low-power 15V industrial or control electronics when the input source is within 9-18VAC.

Q: Is the MDS15A-15 a fit for embedded systems that need a regulated 15V rail?

It can be used where the load specifically requires 15V constant-voltage output and stays within 1A. The input side also needs to match the listed 9-18VAC range.

Q: Can this model support low-power 15V automation modules inside equipment enclosures?

For compact automation modules, the main fit points are its 15V output, 15W rating, and 1A current limit. It is best matched to low-power electronics rather than loads that need more than 15W.

Q: Will the MDS15A-15 handle cold or high-heat operating environments?

The specified operating range is -40C to +90C, so the temperature rating is wide for industrial environments. The specs do not include an IP rating, so temperature capability is stated, but ingress protection is not.

Q: What are the differences between the MDS15A-15 and the other MDS15A versions?

The MDS15A family shares a 15W rating and 9-18VAC input range. Output options are 5V at 3A on MDS15A-05, 12V at 1.25A on MDS15A-12, 15V at 1A on MDS15A-15, and 24V at 625A on MDS15A-24.

SKU:

MDS15A-15

Please for Pricing

Notify me when it's back in stock

Description

Features

DIP 2"x1" package with international standard pinout

2:1 wide input range

Low patient leakage current <5µA

Wide operating temperature range -40~+90℃

Medical safety approved(2xMOPP) according to IEC60601-1

Protections: Short circuit(Continuous)/Overload/Input under voltage

4000VAC high I/O isolation(Reinforced isolation)

3 years warranty

General Specification

Voltage accuracy	±1%
Efficiency	88%
Short circuit protection	Continuous, automatic recovery
Working temperature	-40°C to +90°C
Temp. Coefficient	0.03% / ℃ (0 ~ 70℃)
Dimension (LxWxH) (mm)	50.825.412mm (210.47 inch)

Specifications

Brand

Mean Well
Series

MDS Series
Power Rating

15 Watt
Output Voltage

15 Volt
Rated Current

1 Ampere
Input Voltage

9V~18V
Standards Met

CE,EAC,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

5.08 cm
Width

2.54 cm
Height

1.2 cm
Weight

0.03 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the MDS15A-15 for 15V industrial instrumentation or analog control circuits?

Yes, it is designed as a constant-voltage 15V output unit rated for 15W and 1A. That makes it suitable for low-power 15V industrial or control electronics when the input source is within 9-18VAC.

Is the MDS15A-15 a fit for embedded systems that need a regulated 15V rail?

It can be used where the load specifically requires 15V constant-voltage output and stays within 1A. The input side also needs to match the listed 9-18VAC range.

Can this model support low-power 15V automation modules inside equipment enclosures?

For compact automation modules, the main fit points are its 15V output, 15W rating, and 1A current limit. It is best matched to low-power electronics rather than loads that need more than 15W.

Will the MDS15A-15 handle cold or high-heat operating environments?

The specified operating range is -40C to +90C, so the temperature rating is wide for industrial environments. The specs do not include an IP rating, so temperature capability is stated, but ingress protection is not.

What are the differences between the MDS15A-15 and the other MDS15A versions?

The MDS15A family shares a 15W rating and 9-18VAC input range. Output options are 5V at 3A on MDS15A-05, 12V at 1.25A on MDS15A-12, 15V at 1A on MDS15A-15, and 24V at 625A on MDS15A-24.

Model	Power	Voltage	Current	IP Rating
Mean Well MDS15C-24 DC-DC Converter - 15W - 36~75V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15C-15 DC-DC Converter - 15W - 36~75V in 15V out	15W	15V	1A	Indoor	View
Mean Well MDS15C-12 DC-DC Converter - 15W - 36~75V in 12V out	15W	12V	1.25A	Indoor	View
Mean Well MDS15C-05 DC-DC Converter - 15W - 36~75V in 5V out	15W	5V	3A	Indoor	View
Mean Well MDS15B-24 DC-DC Converter - 15W - 18~36V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15B-15 DC-DC Converter - 15W - 18~36V in 15V out	15W	15V	1A	Indoor	View
Mean Well MDS15B-12 DC-DC Converter - 15W - 18~36V in 12V out	15W	12V	1.25A	Indoor	View
Mean Well MDS15B-05 DC-DC Converter - 15W - 18~36V in 5V out	15W	5V	3A	Indoor	View
Mean Well MDS15A-24 DC-DC Converter - 15W - 9~18V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15A-12 DC-DC Converter - 15W - 9~18V in 12V out	15W	12V	1.25A	Indoor	View
Mean Well MDS15A-05 DC-DC Converter - 15W - 9~18V in 5V out	15W	5V	3A	Indoor	View
