Mean Well

Mean Well MDS15B-05 DC-DC Converter - 15W - 18~36V in 5V out

SKU:
MDS15B-05
Please for Pricing
|

Description

The MDS15B is a 15W Mean Well power converter (input range: 9~18Vdc).

Key Features

  • ✓ Input voltage range: 9~18Vdc
  • ✓ Protections: Short circuit / Overload / Under voltage
  • ✓ Safety approvals: IEC60601-1(LVD) 3 edition, EAC TP TC 004
  • ✓ 3 years warranty

Specifications
  • Brand
    Mean Well
  • Series
    MDS Series
  • Power Rating
    15 Watt
  • Output Voltage
    5 Volt
  • Rated Current
    3 Ampere
  • Input Voltage
    18V~36V
  • Standards Met
    CE,EAC,EMC
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~90°C
  • Warranty
    3 Year
  • Length
    5.08 cm
  • Width
    2.54 cm
  • Height
    1.2 cm
  • Weight
    0.03 kg

File Downloads

::specification::

Payment & Security

Payment methods

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the MDS15B-05 for 5V embedded processors or logic boards in industrial equipment?

Yes, it delivers a constant 5V output rated for 15W and 3A, which suits many low-power embedded and control applications. The input source needs to be within the listed 18-36VAC range.

Is the MDS15B-05 suitable for powering 5V industrial communication or interface electronics?

It can be a good match for 5V control electronics that need constant-voltage output and draw no more than 3A. Its published power ceiling is 15W, with an 18-36VAC input range.

Can this model support 5V automation sensors or small controller subsystems?

For low-power 5V automation loads, the relevant limits are the 5V output, 3A current rating, and 15W total power. It is intended for applications fed from an 18-36VAC source, not for loads outside that input window.

Is the MDS15B-05 meant for outdoor service or only protected enclosures?

The temperature specification is -40C to +90C, so it supports a wide operating range. The provided specs do not list an IP rating, so they support temperature assessment but not a claim of outdoor or sealed-enclosure performance by themselves.

What is the difference between the MDS15B-05 and the other MDS15B converters?

The MDS15B family uses the same 18-36VAC input range and 15W rating across the series. Output options are 5V at 3A for MDS15B-05, 12V at 1.25A for MDS15B-12, 15V at 1A for MDS15B-15, and 24V at 625A for MDS15B-24.
