Mean Well MDS15C-24 DC-DC Converter - 15W - 36~75V in 24V out

Yes, this model is a constant-voltage DC-DC converter with a 24V output and a 15W power rating. Its input range is 36-75V, so it fits systems that need regulated 24V from a higher-voltage DC source. It is best suited to lower-power 24V control, sensing, or relay loads that stay within the 15W rating.

It is sized for compact embedded and industrial electronics that need a 24V constant-voltage output rather than a large bulk power supply. The compact 50.8 × 25.4 × 12.0 mm package and 0.03 kg weight make it easier to use where board or enclosure space is limited. The main sizing limit is its 15W output capacity.

Yes, the 36-75V input range is useful in automation or control equipment where the upstream DC bus can vary within that span. The unit provides a fixed 24V output in constant-voltage mode. That makes it a fit for low-power 24V subsystems instead of variable-output applications.

All MDS15C models in this group are rated at 15W. The MDS15C-05 outputs 5V at 3A, the MDS15C-12 outputs 12V at 1.25A, the MDS15C-15 outputs 15V at 1A, and the MDS15C-24 outputs 24V at 625A. The selection difference here is the output voltage and rated output current, not the series power class.

Its operating temperature range is -40°C to +90°C, so the temperature spec is broad for demanding environments. However, no IP rating is listed in the provided specs, so it should be treated as a converter for protected indoor housings or enclosed equipment rather than exposed outdoor use. Temperature capability and ingress protection are separate considerations.
