Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well MDS15C-12 DC-DC Converter - 15W - 36~75V in 12V out

Q: Can I use the MDS15C-12 to derive 12V for industrial control or monitoring electronics?

Yes, this converter provides a constant 12V output at 1.25A with 15W total power. It is suited to low-power industrial control, monitoring, and embedded electronics that are supplied from a 36-75VAC input range.

Q: Is the MDS15C-12 suitable for embedded systems that need a dedicated 12V auxiliary rail?

Yes, it is built for constant-voltage 12V output and is sized for lighter auxiliary loads up to 15W. That makes it a reasonable choice for embedded processors, interface modules, and small support circuits that need regulated 12V power.

Q: Can this model be used in telecom or automation equipment with a higher-voltage source and 12V subcircuits?

It can fit applications where the source stays within the listed 36-75VAC input range and the downstream section needs 12V constant voltage. The 1.25A output current supports low-power 12V subcircuits rather than larger 12V loads.

Q: Is the MDS15C-12 designed for exposed outdoor environments?

The operating temperature range is -40 C to +90 C, so it is specified for wide temperature variation. Still, no IP rating is shown in the provided data, so the specifications do not establish outdoor sealing or direct exposure protection.

Q: What are the key output options in the MDS15C family?

The family keeps the same 15W platform while changing output voltage and current. The listed models are MDS15C-05 at 5V and 3A, MDS15C-12 at 12V and 1.25A, MDS15C-15 at 15V and 1A, and MDS15C-24 at 24V and 625A.

SKU:

MDS15C-12

Please for Pricing

Notify me when it's back in stock

Description

Features

DIP 2"x1" package with international standard pinout

2:1 wide input range

Low patient leakage current <5µA

Wide operating temperature range -40~+90℃

Medical safety approved(2xMOPP) according to IEC60601-1

Protections: Short circuit(Continuous)/Overload/Input under voltage

4000VAC high I/O isolation(Reinforced isolation)

3 years warranty

General Specification

Voltage accuracy	±1%
Efficiency	88%
Short circuit protection	Continuous, automatic recovery
Working temperature	-40°C to +90°C
Temp. Coefficient	0.03% / ℃ (0 ~ 70℃)
Dimension (LxWxH) (mm)	50.825.412mm (210.47 inch)

Specifications

Brand

Mean Well
Series

MDS Series
Power Rating

15 Watt
Output Voltage

12 Volt
Rated Current

1.25 Ampere
Input Voltage

36V~75V
Standards Met

CE,EAC,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

5.08 cm
Width

2.54 cm
Height

1.2 cm
Weight

0.03 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the MDS15C-12 to derive 12V for industrial control or monitoring electronics?

Yes, this converter provides a constant 12V output at 1.25A with 15W total power. It is suited to low-power industrial control, monitoring, and embedded electronics that are supplied from a 36-75VAC input range.

Is the MDS15C-12 suitable for embedded systems that need a dedicated 12V auxiliary rail?

Yes, it is built for constant-voltage 12V output and is sized for lighter auxiliary loads up to 15W. That makes it a reasonable choice for embedded processors, interface modules, and small support circuits that need regulated 12V power.

Can this model be used in telecom or automation equipment with a higher-voltage source and 12V subcircuits?

It can fit applications where the source stays within the listed 36-75VAC input range and the downstream section needs 12V constant voltage. The 1.25A output current supports low-power 12V subcircuits rather than larger 12V loads.

Is the MDS15C-12 designed for exposed outdoor environments?

The operating temperature range is -40 C to +90 C, so it is specified for wide temperature variation. Still, no IP rating is shown in the provided data, so the specifications do not establish outdoor sealing or direct exposure protection.

What are the key output options in the MDS15C family?

The family keeps the same 15W platform while changing output voltage and current. The listed models are MDS15C-05 at 5V and 3A, MDS15C-12 at 12V and 1.25A, MDS15C-15 at 15V and 1A, and MDS15C-24 at 24V and 625A.

Model	Power	Voltage	Current	IP Rating
Mean Well MDS15C-24 DC-DC Converter - 15W - 36~75V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15C-15 DC-DC Converter - 15W - 36~75V in 15V out	15W	15V	1A	Indoor	View
Mean Well MDS15C-05 DC-DC Converter - 15W - 36~75V in 5V out	15W	5V	3A	Indoor	View
Mean Well MDS15B-24 DC-DC Converter - 15W - 18~36V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15B-15 DC-DC Converter - 15W - 18~36V in 15V out	15W	15V	1A	Indoor	View
Mean Well MDS15B-12 DC-DC Converter - 15W - 18~36V in 12V out	15W	12V	1.25A	Indoor	View
Mean Well MDS15B-05 DC-DC Converter - 15W - 18~36V in 5V out	15W	5V	3A	Indoor	View
Mean Well MDS15A-24 DC-DC Converter - 15W - 9~18V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15A-15 DC-DC Converter - 15W - 9~18V in 15V out	15W	15V	1A	Indoor	View
Mean Well MDS15A-12 DC-DC Converter - 15W - 9~18V in 12V out	15W	12V	1.25A	Indoor	View
Mean Well MDS15A-05 DC-DC Converter - 15W - 9~18V in 5V out	15W	5V	3A	Indoor	View
