Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well MDS15C-05 DC-DC Converter - 15W - 36~75V in 5V out

Q: Can I use the MDS15C-05 to power 5V logic or embedded control electronics from a higher-voltage input bus?

Yes, this model is designed for a 36-75VAC input range and provides a 5V constant-voltage output. With 15W total power and 3A output current, it suits low-power embedded controllers, logic boards, and industrial electronics that need a regulated 5V rail.

Q: Is the MDS15C-05 a good fit for industrial communication or monitoring devices that run on 5V?

It can be, provided the device needs a constant 5V supply and stays within the 15W output limit. The 3A output current makes it more suitable for modest communication, monitoring, or interface electronics than for larger 5V loads.

Q: Can this converter be used for 48V-class control cabinets that need a small 5V auxiliary supply?

It is intended for systems where the available source falls within the listed 36-75VAC input range and the load needs 5V constant voltage. That makes it relevant for higher-voltage industrial or embedded platforms that need a compact 5V auxiliary rail.

Q: Is the MDS15C-05 appropriate for compact electronics assemblies?

Yes, the housing dimensions are 50.8 x 25.4 x 12.0 mm and the unit weight is 0.03 kg. Those specs support use in compact industrial, IT, or embedded assemblies where space and weight are limited.

Q: Can the MDS15C-05 be used outdoors or in unsealed enclosures?

The published operating temperature is -40 C to +90 C, so the temperature range is broad. However, no IP rating is listed, which means the provided specs do not confirm dust or water protection for outdoor or unsealed installations.

Q: How does the MDS15C-05 differ from the other MDS15C models?

All listed MDS15C models are 15W converters for the same family, but the outputs differ. The siblings are MDS15C-05 at 5V and 3A, MDS15C-12 at 12V and 1.25A, MDS15C-15 at 15V and 1A, and MDS15C-24 at 24V and 625A.

SKU:

MDS15C-05

Please for Pricing

Notify me when it's back in stock

Description

Features

DIP 2"x1" package with international standard pinout

2:1 wide input range

Low patient leakage current <5µA

Wide operating temperature range -40~+90℃

Medical safety approved(2xMOPP) according to IEC60601-1

Protections: Short circuit(Continuous)/Overload/Input under voltage

4000VAC high I/O isolation(Reinforced isolation)

3 years warranty

General Specification

Voltage accuracy	±1%
Efficiency	88%
Short circuit protection	Continuous, automatic recovery
Working temperature	-40°C to +90°C
Temp. Coefficient	0.03% / ℃ (0 ~ 70℃)
Dimension (LxWxH) (mm)	50.825.412mm (210.47 inch)

Specifications

Brand

Mean Well
Series

MDS Series
Power Rating

15 Watt
Output Voltage

5 Volt
Rated Current

3 Ampere
Input Voltage

36V~75V
Standards Met

CE,EAC,EMC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~90°C
Warranty

3 Year
Length

5.08 cm
Width

2.54 cm
Height

1.2 cm
Weight

0.03 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the MDS15C-05 to power 5V logic or embedded control electronics from a higher-voltage input bus?

Yes, this model is designed for a 36-75VAC input range and provides a 5V constant-voltage output. With 15W total power and 3A output current, it suits low-power embedded controllers, logic boards, and industrial electronics that need a regulated 5V rail.

Is the MDS15C-05 a good fit for industrial communication or monitoring devices that run on 5V?

It can be, provided the device needs a constant 5V supply and stays within the 15W output limit. The 3A output current makes it more suitable for modest communication, monitoring, or interface electronics than for larger 5V loads.

Can this converter be used for 48V-class control cabinets that need a small 5V auxiliary supply?

It is intended for systems where the available source falls within the listed 36-75VAC input range and the load needs 5V constant voltage. That makes it relevant for higher-voltage industrial or embedded platforms that need a compact 5V auxiliary rail.

Is the MDS15C-05 appropriate for compact electronics assemblies?

Yes, the housing dimensions are 50.8 x 25.4 x 12.0 mm and the unit weight is 0.03 kg. Those specs support use in compact industrial, IT, or embedded assemblies where space and weight are limited.

Can the MDS15C-05 be used outdoors or in unsealed enclosures?

The published operating temperature is -40 C to +90 C, so the temperature range is broad. However, no IP rating is listed, which means the provided specs do not confirm dust or water protection for outdoor or unsealed installations.

How does the MDS15C-05 differ from the other MDS15C models?

All listed MDS15C models are 15W converters for the same family, but the outputs differ. The siblings are MDS15C-05 at 5V and 3A, MDS15C-12 at 12V and 1.25A, MDS15C-15 at 15V and 1A, and MDS15C-24 at 24V and 625A.

Model	Power	Voltage	Current	IP Rating
Mean Well MDS15C-24 DC-DC Converter - 15W - 36~75V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15C-15 DC-DC Converter - 15W - 36~75V in 15V out	15W	15V	1A	Indoor	View
Mean Well MDS15C-12 DC-DC Converter - 15W - 36~75V in 12V out	15W	12V	1.25A	Indoor	View
Mean Well MDS15B-24 DC-DC Converter - 15W - 18~36V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15B-15 DC-DC Converter - 15W - 18~36V in 15V out	15W	15V	1A	Indoor	View
Mean Well MDS15B-12 DC-DC Converter - 15W - 18~36V in 12V out	15W	12V	1.25A	Indoor	View
Mean Well MDS15B-05 DC-DC Converter - 15W - 18~36V in 5V out	15W	5V	3A	Indoor	View
Mean Well MDS15A-24 DC-DC Converter - 15W - 9~18V in 24V out	15W	24V	0.62A	Indoor	View
Mean Well MDS15A-15 DC-DC Converter - 15W - 9~18V in 15V out	15W	15V	1A	Indoor	View
Mean Well MDS15A-12 DC-DC Converter - 15W - 9~18V in 12V out	15W	12V	1.25A	Indoor	View
Mean Well MDS15A-05 DC-DC Converter - 15W - 9~18V in 5V out	15W	5V	3A	Indoor	View
